Dodge Magnum I (2003-2007) 11 15 33 34 can c bus+ can c bus- rf whl speed rf whl speed Wiring diagram

11 15 33 34 CAN C BUS+ CAN C BUS- RF WHL SPEED RF WHL SPEED 15 38 28 6 29 21 TP SENS RTN ETC MOTOR- 21 8 9 12 15 BRAKE SIG CAN C BUS+ CAN C BUS- RF WHL SPEED RF WHL SPEED 25 16 17 36 APPS 1 SIG APPS 1 RTN APPS 2 RTN APPS 2 SIG 34 35 27 CAN C BUS+ CAN C BUS- 9 10 11 8 FUSED B+ CAN C BUS+ CAN C BUS- GROUND ABS ACCEL, COAST ACCELERATOR PEDAL POSITION SENSOR ANTILOCK BRAKES MODULE (RIGHT FRONT OF ENGINE COMPT) BLK/TAN WIRE BRN/DK BLU WIRE BRN/DK GRN WIRE BRN/ORG WIRE BRN/VIO WIRE BRN/WHT WIRE BRN/YEL WIRE COMPUTER DATA LINES SYSTEM DK BLU/GRY WIRE DK BLU/LT GRN WIRE DK GRN/VIO WIRE DK GRN/WHT WIRE ENGINE CONTROLS SYSTEM ETC MOTOR, +/- EXCEPT ABS FRONT CONTROL MODULE (RIGHT SIDE OF ENGINE COMPT) FUSE 19 FUSE 30 HOT AT ALL TIMES ILLUM NCA WIRE PNK/DK BLU WIRE PNK/YEL WIRE POWER DISTRIBUTION CENTER (RIGHT SIDE OF DASH) POWERTRAIN CONTROL MODULE (RIGHT REAR OF ENGINE COMPT) RED/GRY WIRE RIGHT FRONT WHEEL SPEED SENSOR SET, RESUME/ CANCEL STEERING CONTROL MODULE STOP LAMP SWITCH (BASE OF BRAKE PEDAL) WHT/BRN WIRE WHT/LT BLU WIRE WHT/LT GRN WIRE YEL/PNK WIRE
