Anti-lock brakes circuit for Dodge Journey I facelift (2011-2020)

ANTI-LOCK BRAKES MODULE BLK WIRE BODY CONTROL MODULE (RIGHT KICK PANEL) BRAKE FLUID LEVEL SENSOR BRAKE PEDAL TRAVEL SENSOR BRK FLD LVL SIG BRK LMP SW BRK SIG 1 BRN WIRE BRN/WHT WIRE CABIN HEATER 1 RELAY CAN C (+) CENTER HIGH MOUNTED STOP LAMP CLUSTER COMPUTER DATA LINES SYSTEM DK GRN WIRE DK GRN/BRN WIRE DK GRN/GRY WIRE DK GRN/LT BLU WIRE DK GRN/LT GRN WIRE DK GRN/ORG WIRE DK GRN/TAN WIRE DK GRN/VIO WIRE DK GRN/WHT WIRE DK GRN/YEL WIRE DYNAMICS SENSOR (FRONT OF CENTER CONSOLE) FSD B(+) FUSE 141 FUSE 156 FUSE 173 FUSED B (+) GROUND GRY/BLK WIRE HIGH DATA LINK HOT AT ALL TIMES HOT IN ON OR START IGN (RUN-START) LEFT FRONT ABS WHEEL SPEED SENSOR LEFT REAR ABS WHEEL SPEED SENSOR LOW DATA LINK LT FT WHEEL (+) LT RR WHEEL (+) PARKING BRAKE SWITCH PED TRVL SNSR FD PED TRVL SNSR RTN PED TRVL SNSR SIG PNK/LT GRN WIRE POWERTRAIN CONTROL MODULE PRK BRK SW SIG RED WIRE RIGHT FRONT ABS WHEEL SPEED SENSOR RIGHT REAR ABS WHEEL SPEED SENSOR RT FT WHEEL (-) RT RR WHEEL (-) SNSR CLSTR SPLY SNSR GND SNSR SPLY TAN/WHT WIRE UNDERHOOD POWER DISTRIBUTION CENTER VAC PRESS SIG VAC SNSR RTN VAC SNSR SPLY VACUUM PMP RLY CNCT FD VACUUM PMP RLY CTRL VACUUM PRESSURE SENSOR VACUUM PUMP VIO/DK BLU WIRE VIO/LT BLU WIRE WHT/DK BLU WIRE WHT/DK GRN WIRE WHT/YEL WIRE YEL WIRE YEL/LT GRN WIRE
