Dodge Intrepid II (1997-2004) w/ police package w/o police package Wiring diagrams
This page contains all the electrical diagrams for the component. w/ police package w/o police package, in which he is found in the car Dodge Intrepid II (1997-2004). You can view various wiring diagrams where this component is used, as well as go to more detailed diagrams to see the complete connection and interaction in the system. All diagrams have links to quickly jump to the corresponding section with the component for easy viewing..
Wiring diagram w/ police package w/o police package (1 of 2)
A/C COMPRESSOR CLUTCH
AUTOMATIC DAY/NIGHT MIRROR
BATTERY SEAT BELT SWITCH
BLK WIRE
BODY CONTROL MODULE
BRAKE FLUID LEVEL SWITCH
BRAKE LAMP SWITCH
CONTROLLER ANTI-LOCK BRAKE
DATA LINK CONNECTOR (DLC)
EXCEPT 2.7L
FRONT WASHER PUMP MOTOR
FRONT WIPER MOTOR
FRONT WIPER ON/OFF RELAY TRANSMISION CONTROL RELAY
GROUND STRAP
HEADLAMP FLASHER (POLICE PACKAGE)
HEATED OXYGEN SENSOR 1/1 (RIGHT UPSTREAM)
HEATED OXYGEN SENSOR 1/2 (RIGHT DOWNSTREAM)
HEATED OXYGEN SENSOR 2/1 (LEFT UPSTREAM)
HEATED OXYGEN SENSOR 2/2 (LEFT DOWNSTREAM)
IGNITION SWITCH
JUNCTION BLOCK
LEFT FRONT PARK/TURN SIGNAL LAMP
LEFT HIGH BEAM HEADLAMP
LEFT HORN
LEFT LOW BEAM HEADLAMP (DODGE) LEFT FOG LAMP
LEFT SIDE IMPACT AIR BAG CONTROL MODULE
LT GRN WIRE
NCA WIRE
OTHER
OVERHEAD TRAVEL INFORMATION SYSTEM
POWER DISTRIBUTION CENTER
POWER OUTLET
PREMIUM PREMIUM OTHER
RADIATOR FAN MOTOR 1 RADIATOR FAN RELAY 1
RADIATOR FAN RELAY 2
RADIO
RIGHT FRONT PARK/TURN SIGNAL LAMP
RIGHT HORN
RIGHT LOW BEAM HEADLAMP RIGHT HIGH BEAM HEADLAMP
RIGHT SIDE IMPACT AIR BAG CONTROL MODULE
SENTRY KEY IMMOBILIZER MODULE
SPEED CONTROL SERVO
TRACTION CONTROL SWITCH
TRANSMISSION
UNDERHOOD LAMP
W/ POLICE PACKAGE W/O POLICE PACKAGE
WASHER FLUID LEVEL SENSOR
WHT WIRE
Go to component -> Ground distribution circuit (1 of 3) -> W/ POLICE PACKAGE W/O POLICE PACKAGE
Wiring diagram w/ police package w/o police package (2 of 2)
BLK WIRE
BLK/WHT WIRE
BODY CONTROL MODULE TRUNK RELEASE SOLENOID
FUSE 19
FUSE 6
HOT AT ALL TIMES
HOT IN RUN OR ACC
JUNCTION BLOCK (AT LEFT END OF DASH)
PNK WIRE
TRUNK RELEASE SOLENOID/ AJAR SWITCH (CENTER OF DECK LID)
TRUNK RELEASE SWITCH
TRUNK RELEASE SWITCH (LEFT SIDE OF DASH)
W/ POLICE PACKAGE W/O POLICE PACKAGE
Go to component -> Trunk, tailgate, fuel door circuits -> W/ POLICE PACKAGE W/O POLICE PACKAGE
