Dodge Intrepid II (1997-2004) passenger power seat rear riser motor Wiring diagram
This page shows the only wiring diagram for the component.passenger power seat rear riser motor, which is found in the car Dodge Intrepid II (1997-2004). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram passenger power seat rear riser motor (1 of 1)
BLK WIRE
CIRCUIT BREAKER 2
DK BLU WIRE
DOWN
DRIVER POWER SEAT FRONT RISER MOTOR
DRIVER POWER SEAT HORIZONTAL MOTOR
DRIVER POWER SEAT REAR RISER MOTOR
DRIVER POWER SEAT RECLINER MOTOR
DRIVER POWER SEAT SWITCH
GRY WIRE
HOT AT ALL TIMES
JUNCTION BLOCK (AT LEFT END OF DASH)
LT BLU WIRE
LT GRN WIRE
PASSENGER POWER SEAT FRONT RISER MOTOR
PASSENGER POWER SEAT HORIZONTAL MOTOR
PASSENGER POWER SEAT REAR RISER MOTOR
PASSENGER POWER SEAT RECLINER MOTOR
PASSENGER POWER SEAT SWITCH
RED WIRE
RWD
WHT WIRE
YEL WIRE
