Dodge Intrepid II (1997-2004) overhead travel information center Wiring diagram
This page shows the only wiring diagram for the component.overhead travel information center, which is found in the car Dodge Intrepid II (1997-2004). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram overhead travel information center (1 of 1)
AUTOMATIC DAY/NIGHT MIRROR
BLK WIRE
BLK/LT GRN WIRE
BODY CONTROL MODULE
DK BLU WIRE
DK BLU/WHT WIRE
FUSE 14
FUSE 19
FUSED IGN
GARAGE DOOR OPENER
GROUND
HOT AT ALL TIMES
HOT IN RUN OR START
JUNCTION BLOCK (LEFT END OF DASH)
LT GRN WIRE
OVERHEAD TRAVEL INFORMATION CENTER
PCI BUS
PNK FUSED B (+) WIRE
PNK WIRE
PREMIUM ONLY
VIO WIRE
VIO/YEL WIRE
WHT WIRE
YEL WIRE
Go to component -> Overhead console circuit -> OVERHEAD TRAVEL INFORMATION CENTER
