Dodge Intrepid II (1997-2004) low washer fluid indicator Wiring diagram
This page shows the only wiring diagram for the component.low washer fluid indicator, which is found in the car Dodge Intrepid II (1997-2004). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram low washer fluid indicator (1 of 1)
BLK WIRE
BLK/TAN WIRE
BLU WIRE
BODY CONTROL MODULE
BRN WIRE
BRN/WHT WIRE
DK BLU WIRE
DK BLU/WHT WIRE
DK GRN WIRE
DK GRN/RED WIRE
FRONT WASHER PUMP MOTOR (ON WASHER RESERVOIR)
FRONT WIPER HIGH/LOW RELAY (IN POWER DISTRIBUTION CENTER)
FRONT WIPER ON/OFF RELAY (IN POWER DISTRIBUTION CENTER)
FUSE
FUSE 14
FUSE 19
FUSE 5
HOT AT ALL TIMES
HOT IN RUN OR ACC
HOT IN RUN OR START
INSTRUMENT CLUSTER
JUNCTION BLOCK (AT LEFT END OF DASH)
LEFT HEADLAMP
LOW WASHER FLUID INDICATOR
LT GRN WIRE
ORG/ WIRE
POWER DISTRIBUTION CENTER (ON LEFT SIDE OF ENGINE COMPARTMENT)
RED WIRE
RED/ORG WIRE
RED/VIO WIRE
RED/YEL WIRE
TAN WIRE
VIO WIRE
WASH SWITCH
WASHER FLUID LEVEL SWITCH (BEHIND LEFT FRONT FASCIA, IN WASHER RESERVOIR)
WASHER FLUID SWITCH SENSE
WHT WIRE
WIPER SWITCH
YEL WIRE
Go to component -> Wiper/washer circuit -> LOW WASHER FLUID INDICATOR
