Dodge Intrepid II (1997-2004) fog lamp control Wiring diagrams
This page contains all the electrical diagrams for the component. fog lamp control, in which he is found in the car Dodge Intrepid II (1997-2004). You can view various wiring diagrams where this component is used, as well as go to more detailed diagrams to see the complete connection and interaction in the system. All diagrams have links to quickly jump to the corresponding section with the component for easy viewing..
Wiring diagram fog lamp control (1 of 2)
BLK WIRE
BLK/LT GRN WIRE
BLU LT WIRE
BODY CONTROL MODULE
BRN/WHT WIRE
FLASH TO PASS HIGH BEAM
FOG
FOG INDICATOR
FOG LAMP CONTROL
FOG LAMP RELAY
FUSE
FUSE 10
FUSE 11
FUSE 12
FUSE 16
FUSE 2
FUSE 3
FUSE 7
HEAD AUTO
HEADLAMP DIMMER SWITCH (PART OF MULTI-FUNCTION SWITCH)
HEADLAMP SWITCH
HEADLAMP SWITCH MUX
HEADLAMP SWITCH RETURN
HIGH BEAM HEADLAMP RELAY
HIGH BEAM INDICATOR
HOT AT ALL TIMES
INSTRUMENT CLUSTER
INTREPID
JUNCTION BLOCK (AT LEFT END OF DASH)
LEFT FOG LAMP
LEFT HIGH BEAM HEADLAMP
LEFT LOW BEAM HEADLAMP
LOW BEAM HEADLAMP CONTROL
LOW BEAM HEADLAMP RELAY
LT BLU WIRE
LT BLU/RED WIRE
ORG/ WIRE
PARK OFF
PNK/RED WIRE
POWER DISTRIBUTION CENTER (ON LEFT SIDE OF ENGINE COMPARTMENT)
RED WIRE
RED/ORG WIRE
RED/TAN WIRE
RIGHT FOG LAMP
RIGHT FOG LAMP LEFT FOG LAMP
RIGHT HIGH BEAM HEADLAMP
RIGHT LOW BEAM HEADLAMP
SWITCH ILLUM.
VIO WIRE
VIO/RED WIRE
WHT LT GRN/ WIRE
WHT WIRE
WHT/LT GRN WIRE
YEL WIRE
Go to component -> Headlight circuit, without drl -> FOG LAMP CONTROL
Wiring diagram fog lamp control (2 of 2)
1 2 3 4 5 6 HI BM OUT HI BM OUT HI BM OUT HI BM OUT IGN GROUND
1 2 3 4 HI BM OUT HI BM OUT HI BM OUT HI BM OUT
BLK WIRE
BLK/LT GRN WIRE
BLU LT WIRE
BODY CONTROL MODULE
BRN/WHT WIRE
DK BLU WIRE
FLASH TO PASS HIGH BEAM
FOG
FOG INDICATOR
FOG LAMP CONTROL
FOG LAMP RELAY
FUSE
FUSE 10
FUSE 11
FUSE 12
FUSE 16
FUSE 2
FUSE 3
FUSE 5
FUSE 7
HEAD AUTO
HEADLAMP DIMMER SWITCH (PART OF MULTI-FUNCTION SWITCH)
HEADLAMP FLASHER (BEHIND PARK BRAKE LEVER)
HEADLAMP FLASHER CAP (BEHIND PARK BRAKE LEVER)
HEADLAMP SWITCH
HEADLAMP SWITCH MUX
HEADLAMP SWITCH RETURN
HIGH BEAM HEADLAMP RELAY
HIGH BEAM INDICATOR
HOT AT ALL TIMES
HOT IN ACC OR RUN
INSTRUMENT CLUSTER
JUNCTION BLOCK (AT LEFT END OF DASH)
LEFT FOG LAMP
LEFT HIGH BEAM HEADLAMP
LEFT LOW BEAM HEADLAMP
LOW BEAM HEADLAMP CONTROL
LOW BEAM HEADLAMP RELAY
LT BLU WIRE
LT BLU/RED WIRE
ORG/ WIRE
ORG/WHT WIRE
PARK OFF
PNK/RED WIRE
POWER DISTRIBUTION CENTER (ON LEFT SIDE OF ENGINE COMPARTMENT)
RED WIRE
RED/ORG WIRE
RED/TAN WIRE
RIGHT FOG LAMP
RIGHT HIGH BEAM HEADLAMP
RIGHT LOW BEAM HEADLAMP
SWITCH ILLUM.
VIO WIRE
VIO/RED WIRE
WHT LT GRN/ WIRE
WHT WIRE
WHT/LT GRN WIRE
YEL WIRE
Go to component -> Headlight circuit, without drl with police option -> FOG LAMP CONTROL
