Dodge Intrepid II (1997-2004) 38 36 26 25 37 pci bus sci transmit sci receive sci receive sci transmit Wiring diagram

38 36 26 25 37 PCI BUS SCI TRANSMIT SCI RECEIVE SCI RECEIVE SCI TRANSMIT AIR BAG CONTROL MODULE (FORWARD OF CENTER CONSOLE) AUTOMATIC TEMPERATURE CONTROL HEAD BLK WIRE BLK/LT GRN WIRE BODY CONTROL MODULE COMPACT DISC CHANGER CONTROLLER ANTI-LOCK BRAKE (LEFT FENDER SIDE SHIELD) DATA LINK CONNECTOR (DLC) (BELOW DASH, TO LEFT OF STEERING COLUMN) FUSE 1 FUSE 18 HOT AT ALL TIMES HOT IN OFF, RUN OR START INSTRUMENT CLUSTER JUNCTION BLOCK (AT LEFT END OF DASH) LEFT SIDE IMPACT AIR BAG CONTROL MODULE (LEFT "B" PILLAR) LT GRN WIRE MEMORY HEATED SEAT/MIRROR MODULE OVERHEAD TRAVEL INFORMATION SYSTEM PCI BUS PCI BUS (ATC) PCI BUS (CAB) PCI BUS (PCM) PCI BUS (DLC) PCI BUS (ORC) PCI BUS (RADIO) PCI BUS (SKIM) PCI BUS (MIC) PCI BUS (SIACM) PNK/TAN WIRE POWERTRAIN CONTROL MODULE (IN LEFT REAR OF ENGINE COMPT) RADIO RED WIRE RED/WHT WIRE RIGHT SIDE IMPACT AIR BAG CONTROL MODULE (RIGHT "B" PILLAR) SCI RECEIVE (TCM/BCM) SENTRY KEY IMMOBILIZER MODULE (IN STEERING COLUMN) VIO/ORG WIRE VIO/YEL WIRE W/ MEMORY W/O MEMORY WHT/DK GRN WIRE
