Dodge Intrepid II (1997-2004) 21 38 a/c press sig pci bus Wiring diagram

1 2 3 SENSOR GROUND 2 1 GROUND SIGNAL 21 38 A/C PRESS SIG PCI BUS 27 29 SENSOR GND 5 VOLT SUPPLY 4 6 11 32 RELAY CTRL RELAY CTRL RELAY CTRL AMBIENT TEMP A/C COMPRESSOR CLUTCH A/C COMPRESSOR CLUTCH RELAY A/C PRESS SIG BLK WIRE BLK/LT BLU WIRE BLK/TAN WIRE BLOWER MOTOR RESISTOR BLOCK (ON LOWER RIGHT SIDE OF HVAC ASSEMBLY) BLU WIRE BODY CONTROL MODULE (AT LEFT END OF DASH, ATTACHED TO JUNCTION BLOCK) BRN/WHT WIRE CLOCKSPRING (BEHIND STEERING WHEEL, IN STEERING COLUMN) DEFOGGER SYSTEM DK BLU WIRE DK BLU/BLK WIRE DK BLU/GRY WIRE DK BLU/ORG WIRE DK BLU/PNK WIRE DK BLU/RED WIRE DK BLU/WHT WIRE DK GRN/YEL WIRE EVAP TEMP SIG A/C MODE MUX EVAPORATOR TEMPERATURE SENSOR (IN HVAC ASSEMBLY, ON FACE OF EVAPORATOR) FUSE 17 FUSE 21 FUSE 23 GRN WIRE GROUND GRY/DK BLU WIRE HIGH BLOWER MTR HOT IN RUN HOT IN RUN OR START JUNCTION BLOCK (AT LEFT END OF DASH) LOW BLOWER MTR LT BLU WIRE LT GRN WIRE LT GRN/BLK WIRE MANUAL TEMPERATURE CONTROL HEAD NCA WIRE ORG/ WIRE PANEL LAMPS DRVR PCI BUS PNK/DK BLU WIRE POWER DISTRIBUTION CENTER (ON LEFT SIDE OF ENGINE COMPARTMENT) POWERTRAIN CONTROL MODULE (PCM) (IN LEFT REAR OF ENGINE COMPARTMENT) REAR WDO DEFOG RED/BRN WIRE RED/TAN WIRE RED/WHT WIRE SOUND SYSTEMS TAN WIRE TEMP SELECT A/C MODE SW MUX VIO/LT GRN WIRE VIO/PNK WIRE VIO/WHT WIRE VIO/YEL WIRE WHT WIRE YEL/BLK WIRE YEL/ORG WIRE YEL/WHT WIRE
