Dodge Durango III (2010-2013) Hands free module circuit

1 2 3 4 5 6 7 8 9 10 11 12 13 14 15 16 17 18 19 20 21 22 IOD FD BLK WIRE CAN IHS BUS (-) CAN IHS BUS (-) HF MIC 2 IN (+) COMPUTER DATA LINES SYSTEM DK BLU/DK GRN WIRE DK BLU/LT BLU WIRE DK GRN WIRE DK GRN/LT BLU WIRE DK GRN/ORG WIRE DK GRN/YEL WIRE FUSE HANDS FREE MODULE (AT LEFT "A" PILLAR) HF AUDO OUTPUT COM HF MIC 2 IN+ HF MIC HSD FD HF MIC HSD FD HF MIC REF GND HF MIC REF HNDS FREE MIC IN (+) HNDS FREE MIC IN (-) HNDS FREE MIC IN- HOT AT ALL TIMES INSIDE REARVIEW MIRROR LEFT HF AUDO OUTPUT LEFT HF AUDO OUTPUT RIGHT HF AUDO OUTPUT HF AUDO OUTPUT COM LT BLU/DK GRN WIRE ORG/GRY WIRE RADIO RED/WHT WIRE RIGHT HF AUDO OUTPUT TOTALLY INTEGRATED POWER MODULE (RIGHT SIDE OF ENGINE COMPT) WHT/GRY WIRE WHT/ORG WIRE
