Dodge Durango III (2010-2013) lmbr down driv wiring diagram
This page shows the only wiring diagram for the component.lmbr down driv, which is found in the car Dodge Durango III (2010-2013). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
lmbr down driv wiring diagram (1 of 1)
BLK WIRE
BRN LT GRN/ WIRE
DEFLATE/ REARWARD INFLATE/ FORWARD
DRIVER FORWARD/ REARWARD SEAT LUMBAR SWITCH
DRIVER LUMBAR SEAT ADJUSTER SWITCH
DRIVER UP/DOWN SEAT LUMBAR MOTOR
FRONT PASSENGER FORWARD/REARWARD SEAT LUMBAR MOTOR
FRONT PASSENGER UP/DOWN SEAT LUMBAR MOTOR
FT BATT FD
HOT AT ALL TIMES
INFLATE/ FORWARD DEFLATE/ REARWARD
LMBR DOWN DRIV
LMBR DOWN PASS
LMBR UP DRIV
LMBR UP PASS
LT GRN WIRE
LT GRN/BRN WIRE
LT GRN/ORG WIRE
LT GRN/VIO WIRE
LT GRN/WHT WIRE
LT GRN/YEL WIRE
ORG/RED WIRE
PASSENGER LUMBAR SEAT ADJUSTER SWITCH
POWER SEAT CIRCUIT BREAKER
REAR PASSENGER FORWARD/REARWARD SEAT LUMBAR MOTOR
REAR PASSENGER UP/DOWN SEAT LUMBAR MOTOR
Go to component -> Lumbar circuit -> LMBR DOWN DRIV
