Dodge Durango II (2003-2006) sdars audio rtn Wiring diagram
This page shows the only wiring diagram for the component.sdars audio rtn, which is found in the car Dodge Durango II (2003-2006). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram sdars audio rtn (1 of 1)
BLK WIRE
CAN B BUS (+)
COMPUTER DATA LINES SYSTEM
DK BLU/RED WIRE
DK GRN/RED WIRE
FUSE 11
FUSED B (+)
GROUND
GRY WIRE
GRY/DK GRN WIRE
GRY/LT BLU WIRE
GRY/LT GRN WIRE
HOT AT ALL TIMES
JUNCTION BLOCK (LEFT KICK PANEL)
LT BLU/PNK WIRE
LT GRN WIRE
LT GRN/RED WIRE
MONITOR/DVD MEDIA SYSTEM
RADIO
SDARS AUDIO RTN
SDARS AUDIO RTN VDO-AUX
VDO-AUX
VDO-AUX AUDIO LT
VDO-AUX AUDIO RT
VDO-AUX AUDIO RTN/COMMON
WHT WIRE
WHT/ORG WIRE
Go to component -> Dvd player circuit -> SDARS AUDIO RTN
