Dodge Durango II (2003-2006) powertrain control module (right side of engine compt) generator wiring diagram
This page shows the only wiring diagram for the component.powertrain control module (right side of engine compt) generator, which is found in the car Dodge Durango II (2003-2006). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
powertrain control module (right side of engine compt) generator wiring diagram (1 of 1)
3.7L
4.7L/ 5.7L
4.7L/ 5.7L 3.7L
BATT TEMP RETURN BATT TEMP SIGNAL
BATTERY
BATTERY TEMPERATURE SENSOR (RIGHT FRONT OF ENGINE COMPT)
BLK WIRE
BLK/RED WIRE
BLU WIRE
BRN/GRY WIRE
DK BLU WIRE
FRONT CONTROL MODULE
FUSE
FUSE 22
FUSED B (+)
FUSED B(+) GEN FIELD (LEFT FRONT OF ENGINE)
FUSIBLE LINK (8 GA-
GRY WIRE
LT BLU WIRE
NCA WIRE
ORG/ WIRE
ORG/GRY WIRE
POWER DISTRIBUTION CENTER (LEFT SIDE OF ENGINE COMPT)
POWER DISTRIBUTION MODULE (LEFT SIDE OF ENGINE COMPT)
POWERTRAIN CONTROL MODULE (RIGHT SIDE OF ENGINE COMPT) GENERATOR
RED WIRE
STARTER B(+) (LOWER RIGHT SIDE OF ENGINE)
VIO WIRE
YEL WIRE
Go to component -> Charging circuit -> POWERTRAIN CONTROL MODULE (RIGHT SIDE OF ENGINE COMPT) GENERATOR
