Dodge Durango II (2003-2006) adjustable pedals rly control 46 pdm Wiring diagram
This page shows the only wiring diagram for the component.adjustable pedals rly control 46 pdm, which is found in the car Dodge Durango II (2003-2006). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram adjustable pedals rly control 46 pdm (1 of 1)
ADJUSTABLE PEDALS MOTOR (LEFT CENTER OF DASH)
ADJUSTABLE PEDALS RELAY
ADJUSTABLE PEDALS RLY CONTROL 46 PDM
ADJUSTABLE PEDALS SWITCH (LEFT SIDE OF DASH)
BLK WIRE
BLK/LT BLU WIRE
FRONT CONTROL MODULE
FUSE 14 MODULE (LEFT SIDE OF ENGINE COMPT)
HOT AT ALL TIMES
LT BLU WIRE
LT GRN WIRE
LT GRN/TAN WIRE
ORG/BLK WIRE
POWER DISTRIBUTION
RED/LT BLU WIRE
TAN WIRE
WHT WIRE
Go to component -> Adjustable pedal circuit -> ADJUSTABLE PEDALS RLY CONTROL 46 PDM
