Dodge Durango II (2003-2006) adjust pedals sens sig Wiring diagram

1 2 3 4 5 6 7 8 9 10 11 12 13 14 ADJUST PEDALS MOTOR FWD ADJUST PEDALS MOTOR RWD 1 2 3 4 5 6 DRV SEAT RECLINER POS SENS GND DRV SEAT RECLINER UP DRV ADJUST PEDALS SENS RTN ADJUST PEDALS SENS SIG ADJUST PEDALS SW RWD ADJUST PEDALS SW FWD ADJUSTABLE PEDALS MOTOR (LEFT CENTER OF DASH) ADJUSTABLE PEDALS SENSOR (LEFT SIDE OF DASH) ADJUSTABLE PEDALS SWITCH (LEFT SIDE OF DASH) BLK/LT BLU WIRE BLU WIRE BLU/WHT WIRE BRN WIRE CAN B BUS (+) CAN B BUS (+) FUSED B(+) ADJUST PEDALS SENS SUPPLY GND COMPUTER DATA LINES SYSTEM DRIVER SEAT HORIZONTAL ADJUSTER MOTOR (UNDER DRIVER SEAT) DRIVER SEAT RECLINER ADJUSTER DRIVER SEAT SWITCH DRV SEAT HORIZ FWD DRV DRV SEAT HORIZ RWD DRV DRV SEAT REAR VERT DOWN DRV DRV SEAT RECLINER DOWN DRV DRV SEAT RECLINER POS SNS DRV SEAT SW MUX SUPPLY FORWARD/ FRONT DRIVER SEAT VERTICAL ADJUSTER MOTOR (UNDER DRIVER SEAT) FUSE 5 GRY WIRE HOT AT ALL TIMES LT BLU/VIO WIRE LT GRN WIRE LT GRN/BRN WIRE LT GRN/DK BLU WIRE LT GRN/DK GRN WIRE LT GRN/GRY WIRE LT GRN/LT BLU WIRE LT GRN/TAN WIRE LT GRN/WHT WIRE LT GRN/YEL WIRE MEMORY SEAT MODULE (UNDER DRIVER SEAT) MOTOR (UNDER DRIVER SEAT) ORG/BRN WIRE ORG/WHT WIRE POWER DISTRIBUTION CENTER (LEFT SIDE OF ENGINE COMPT) REAR DRIVER SEAT VERTICAL ADJUSTER MOTOR (UNDER DRIVER SEAT) REARWARD RED WIRE RED/GRY WIRE VIO WIRE VIO/BRN WIRE VIO/DK BLU WIRE VIO/GRY WIRE VIO/LT GRN WIRE VIO/ORG WIRE VIO/TAN WIRE VIO/WHT WIRE VIO/YEL WIRE WHT WIRE WHT/ORG WIRE YEL/VIO WIRE
