Dodge Durango II (2003-2006) 15 21 21 27 29 29 tps return tps sig 1 tps sens in sensor gnd tps sig 2 Wiring diagrams
This page contains all the electrical diagrams for the component. 15 21 21 27 29 29 tps return tps sig 1 tps sens in sensor gnd tps sig 2, in which he is found in the car Dodge Durango II (2003-2006). You can view various wiring diagrams where this component is used, as well as go to more detailed diagrams to see the complete connection and interaction in the system. All diagrams have links to quickly jump to the corresponding section with the component for easy viewing..
Wiring diagram 15 21 21 27 29 29 tps return tps sig 1 tps sens in sensor gnd tps sig 2 (1 of 2)
15 21 21 27 29 29 TPS RETURN TPS SIG 1 TPS SENS IN SENSOR GND TPS SIG 2
9 11 12 18 29 30 27 GROUND IGN POWER IGN POWER GROUND FUSED B(+) IGN POWER
BLK WIRE
BLK/RED WIRE
BRN/BLU WIRE
BRN/PNK WIRE
BRN/VIO WIRE
BRN/YEL WIRE
DK BLU/DK GRN WIRE
DK GRN WIRE
DK GRN/BRN WIRE
DK GRN/DK BLU WIRE
DK GRN/VIO WIRE
DK GRN/YEL WIRE
ENGINE CONTROLS SYSTEM
FUSE 18
FUSE 32
FUSE 34
HOT AT ALL TIMES
HOT IN OFF, RUN OR START
HOT IN RUN OR START
INPUT SPEED SENSOR (LEFT SIDE OF TRANS- MISSION)
JUNCTION BLOCK (LEFT SIDE OF DASH)
JUNCTION BLOCK (LEFT SIDE OF DASH) (LEFT KICK PANEL)
LINE PRESSURE SENSOR (RIGHT SIDE OF TRANS- MISSION)
MS SOL CTRL
OD OFF SW SENS TRANS CTRL RELAY TRANS CTRL RELAY
ORG/GRY WIRE
OUTPUT SPEED SENSOR (LEFT SIDE OF TRANS- MISSION)
OVERDRIVE SWITCH
PARK/NEUTRAL
PNK/DK GRN WIRE
PNK/GRY WIRE
PNK/LT BLU WIRE
PNK/YEL WIRE
POWER DISTRIBUTION CENTER (LEFT SIDE OF ENGINE COMPT) FUSE 22
POWERTRAIN CONTROL MODULE (RIGHT SIDE ON ENGINE COMPT)
TRANS CTRL RELAY LOW/REV PRESS SW
TRANS CTRL RLY OUT
UD PRES SW SENS OD PRES SW SENS
UNDRDRIVE SOL CTRL LR SOL CTRL PRESSURE CNTL SOL GROUND GROUND GROUND
VIO/BRN WIRE
VIO/DK BLU WIRE
VIO/DK GRN WIRE
VIO/GRY WIRE
VIO/ORG WIRE
VIO/RED WIRE
VIO/WHT WIRE
YEL/DK BLU WIRE
YEL/DK GRN WIRE
YEL/LT BLU WIRE
YEL/ORG WIRE
YEL/PNK WIRE
YEL/VIO WIRE
YEL/WHT WIRE
Go to component -> 4.7l, a/t circuit (2 of 2) -> 15 21 21 27 29 29 TPS RETURN TPS SIG 1 TPS SENS IN SENSOR GND TPS SIG 2
Wiring diagram 15 21 21 27 29 29 tps return tps sig 1 tps sens in sensor gnd tps sig 2 (2 of 2)
15 21 21 27 29 29 TPS RETURN TPS SIG 1 TPS SENS IN SENSOR GND TPS SIG 2
9 11 12 18 29 30 27 GROUND IGN POWER IGN POWER GROUND FUSED B(+) IGN POWER
BLK WIRE
BLK/RED WIRE
BRN/BLU WIRE
BRN/PNK WIRE
BRN/VIO WIRE
BRN/YEL WIRE
DK BLU/DK GRN WIRE
DK GRN WIRE
DK GRN/BRN WIRE
DK GRN/DK BLU WIRE
DK GRN/VIO WIRE
DK GRN/YEL WIRE
ENGINE CONTROLS SYSTEM
FUSE 18
FUSE 32
FUSE 34
HOT AT ALL TIMES
HOT IN OFF, RUN OR START
HOT IN RUN OR START
INPUT SPEED SENSOR (LEFT SIDE OF TRANS- MISSION)
JUNCTION BLOCK (LEFT SIDE OF DASH)
JUNCTION BLOCK (LEFT SIDE OF DASH) (LEFT KICK PANEL)
LINE PRESSURE SENSOR (RIGHT SIDE OF TRANS- MISSION)
MS SOL CTRL
OD OFF SW SENS TRANS CTRL RELAY TRANS CTRL RELAY
ORG/GRY WIRE
OUTPUT SPEED SENSOR (LEFT SIDE OF TRANS- MISSION)
OVERDRIVE SWITCH
PARK/NEUTRAL
PNK/DK GRN WIRE
PNK/GRY WIRE
PNK/LT BLU WIRE
PNK/YEL WIRE
POWER DISTRIBUTION CENTER (LEFT SIDE OF ENGINE COMPT) FUSE 22
POWERTRAIN CONTROL MODULE (RIGHT SIDE ON ENGINE COMPT)
TRANS CTRL RELAY LOW/REV PRESS SW
TRANS CTRL RLY OUT
UD PRES SW SENS OD PRES SW SENS
UNDRDRIVE SOL CTRL LR SOL CTRL PRESSURE CNTL SOL GROUND GROUND GROUND
VIO/BRN WIRE
VIO/DK BLU WIRE
VIO/DK GRN WIRE
VIO/GRY WIRE
VIO/ORG WIRE
VIO/RED WIRE
VIO/WHT WIRE
YEL/DK BLU WIRE
YEL/DK GRN WIRE
YEL/LT BLU WIRE
YEL/ORG WIRE
YEL/PNK WIRE
YEL/VIO WIRE
YEL/WHT WIRE
Go to component -> 5.7l, a/t circuit (2 of 2) -> 15 21 21 27 29 29 TPS RETURN TPS SIG 1 TPS SENS IN SENSOR GND TPS SIG 2
