Dodge Durango II (2003-2006) 10 pdm defogger relay control Wiring diagram
This page shows the only wiring diagram for the component.10 pdm defogger relay control, which is found in the car Dodge Durango II (2003-2006). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram 10 pdm defogger relay control (1 of 1)
10 PDM DEFOGGER RELAY CONTROL
BLK WIRE
DK BLU WIRE
DRIVER OUTSIDE REARVIEW MIRROR
FRONT CONTROL MODULE
FUSE 12
FUSE 2
FUSE 24
GRY WIRE
HOT AT ALL TIMES
HOT IN
JUNCTION BLOCK (LEFT KICK PANEL)
ORG/BRN WIRE
PASSENGER OUTSIDE REARVIEW MIRROR
POWER DISTRIBUTION MODULE (LEFT SIDE OF ENGINE COMPT)
REAR DEFOGGER GRID
REAR WINDOW DEFOGGER RELAY
RUN WIRE
WHT WIRE
YEL WIRE
Go to component -> Defoggers circuit -> 10 PDM DEFOGGER RELAY CONTROL
