Interior light circuit for Dodge Durango I (1997-2003)

1 2 3 4 INT LIGHTS DIMMER PARADE DOME CARGO 1 6 FUSED (B+) FUSED (B+) 16 1 13 15 INTERIOR LAMP DRIV CTSY LAMP DRIV PASS DR AJAR DRIVER DR AJAR A/C HEATER CONTROL BLK WIRE BLK/ORG WIRE BLK/RED WIRE BLK/YEL WIRE CENTRAL TIMER MODULE (BEHIND RIGHT SIDE OF DASH) CIGAR LIGHTER DRIVER DOOR POWER LOCK MOTOR/ AJAR SWITCH FUSE 3 FUSE 4 FUSE 9 GRY/BLK WIRE HEADLAMP SWITCH HOT AT ALL TIMES IGNITION SWITCH KEY IN JUNCTION BLOCK (ON LEFT END OF DASH) LEFT REAR DOOR POWER LOCK MOTOR/ AJAR SWITCH LT BLU WIRE LT GRN WIRE OFF PARK HEAD ORG/ WIRE OVERHEAD CONSOLE PARK LAMP RELAY PASSENGER DOOR POWER LOCK MOTOR/ AJAR SWITCH PNK/DK BLU WIRE PNK/LT BLU WIRE POWER DISTRIBUTION CENTER (ON LEFT FRONT INNER FENDER) FUSE 12 REAR A/C HEATER CONTROL RED WIRE RED/LT GRN WIRE RED/TAN WIRE RED/YEL WIRE RIGHT REAR DOOR POWER LOCK MOTOR/ AJAR SWITCH SENSOR RETURN SHIFT BEZEL LAMP TAN WIRE TAN/RED WIRE TO JUNCTION BLOCK (DIAGRAM 2 OF 2) TRANSFER CASE SELECTOR SWITCH WHT WIRE WHT/DK GRN WIRE YEL WIRE YEL/VIO WIRE

1 5 LMP DIM SW SIG HDLMP SW OUT 5 7 4 LMP DIM SW SIG B+ HDLMP SW OUT BLK WIRE CENTER CONSOLE LAMP DRIVER DOOR MODULE FROM JUNCTION BLOCK (DIAGRAM 1 OF 2) FRONT DOME LAMP FUSE 1 GLOVE BOX LAMP/ SWITCH GROUND HOT AT ALL TIMES INSTRUMENT CLUSTER J/C 4 (BEHIND LEFT SIDE OF DASH) JUNCTION BLOCK (ON LEFT END OF DASH) LEFT VISOR/ VANITY LAMP (W/ LIGHT PACKAGE) LIFTGATE LAMP ORG/ WIRE OVERHEAD CONSOLE PNK WIRE RADIO REAR DOME LAMP RIGHT VISOR/ VANITY LAMP (W/ LIGHT PACKAGE) SENTRY KEY IMMOBILIZER MODULE (ON STEERING COLUMN) VIO WIRE W/ LIGHT PACKAGE W/O LIGHT PACKAGE WHT WIRE YEL WIRE YEL/VIO WIRE
