Back-up lamps circuit for Dodge Durango I (1997-2003)
Back-up lamps circuit
4.7L
AUTOMATIC DAY/NIGHT MIRROR
BLK WIRE
BRN/LT GRN WIRE
HOT IN RUN FUSE 26
J/C 1 (IN POWER DISTRIBUTION CENTER)
JUNCTION BLOCK
LEFT BACK-UP LAMP
LEFT TAIL LAMP ASSEMBLY
RIGHT BACK-UP LAMP
RIGHT TAIL LAMP ASSEMBLY
TRAILER TOW CONNECTOR
TRANSMISSION RANGE SENSOR (INSIDE TRANSMISSION, ON TOP OF VALVE)
TRANSMISSION SOLENOID/TRS ASSEMBLY (LEFT SIDE OF TRANSMISSION)
VIO/BLK WIRE
