Anti-lock brake circuits for Dodge Durango I (1997-2003)

1 2 3 4 5 REAR WHEEL SENSOR (+) BLK WIRE BLK/LT GRN WIRE BLK/PNK WIRE BRAKE LAMP SWITCH (ON BRAKE PEDAL SUPPORT) BRAKE PRESSURE SWITCH (IN BRAKE SYSTEM COMBINATION VALVE) BRAKE PRESSURE SWITCH VEHICLE SPEED SIG GROUND BATTERY BRN/WHT WIRE CONTROLLER ANTI-LOCK BRAKE (MOUNTED ON TOP OF HYDRAULIC CONTROL UNIT) DATA LINK CONNECTOR (UNDER DASH LEFT OF STEERING COLUMN) DIAGNOSTIC JUNCTION PORT (UNDER LEFT SIDE OF DASH) FUSE 27 FUSE 8 GROUND BATTERY REAR WHEEL SENSOR (-) STOPLIGHT SW SENSE SIG 7 8 9 10 11 12 13 14 HOT AT ALL TIMES HOT IN RUN JUNCTION BLOCK (ON LEFT END OF DASH) J/C 2 (IN PDC) PCI BUS IGNITION POWER DISTRIBUTION CENTER (ON LEFT INNER FENDER) REAR WHEEL SPEED SENSOR (ON TOP OF DIFFERENTIAL HOUSING) RED WIRE RED/DK BLU WIRE RED/DK GRN WIRE RED/GRY WIRE RED/VIO WIRE STOPLIGHT SW SENSE SIGNAL VEHICLE SPEED SIGNAL VIO/YEL WIRE W/ A/T ONLY W/ ALL WHEEL ABS WHT WIRE WHT/DK BLU WIRE WHT/ORG WIRE WHT/PNK WIRE WHT/VIO WIRE
