Dodge Durango I (1997-2003) gen srce wiring diagram
This page shows the only wiring diagram for the component.gen srce, which is found in the car Dodge Durango I (1997-2003). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
gen srce wiring diagram (1 of 1)
"CHECK GAUGES" INDICATOR
4.7L
4.7L 5.9L
BATTERY
BATTERY TEMPERATURE SENSOR (ATTACHED TO BATTERY TRAY)
BLK WIRE
BLK/GRY WIRE
BLK/LT BLU WIRE
CHECK GAUGES IND CTRL
COMPUTER DATA LINES SYSTEM
DK BLU/WHT WIRE
DK GRN WIRE
ENGINE CONTROL SYSTEM
ENGINE STARTER MOTOR
FUSE 14
FUSIBLE LINK (8 GA-
GEN FLD
GEN SRCE
GENERATOR
GRY WIRE
HOT IN RUN OR START
INSTRUMENT CLUSTER
JOINT CONNECTOR 1 (IN PDC)
JUNCTION BLOCK (ON LEFT END OF DASH)
LEAK DETECTION PUMP (UNDER BATTERY TRAY, PDC) SENS GND GEN SRCE
LT BLU WIRE
PCI BUS
PNK/YEL WIRE
POWER DISTRIBUTION CENTER (ON LEFT FRONT INNER FENDER) FUSE 2
POWERTRAIN CONTROL MODULE (ON RIGHT FRONT INNER FENDER)
RED WIRE
SENS SIG
TRANSMISSION CONTROL RELAY (IN PDC)
VIO/YEL WIRE
VOLTS
WHT WIRE
WHT/DK BLU WIRE
Go to component -> Charging circuit -> GEN SRCE
