Electronic power steering circuit for Dodge Dart PF (2012-2016)

Electronic power steering circuit

Get access

1 2 3 CAN C (-) CAN C (+) FUSED IGNITION SWITCH OUTPUT (RUN-START) 1 2 GND B+ BLK WIRE CAN IHS (-) CLUSTER COMPUTER DATA LINES SYSTEM ELECTRONIC POWER STEERING (EPS) CONTROL MODULE (ON STEERING RACK) FUSE HOT AT ALL TIMES BATTERY FUSE BLOCK HOT W/ RUN/START RELAY ENERGIZED RED WIRE RED/LT GRN WIRE UNDERHOOD POWER DISTRIBUTION CENTER (LEFT REAR CORNER OF ENGINE COMPT) VIO/WHT WIRE WHT WIRE WHT/BLK WIRE YEL WIRE YEL/BRN WIRE
