Dodge Dart PF (2012-2016) washer fld lev sw sens Wiring diagram
This page shows the only wiring diagram for the component.washer fld lev sw sens, which is found in the car Dodge Dart PF (2012-2016). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram washer fld lev sw sens (1 of 1)
13 14 CAN IHS (+) CAN IHS (-)
BLK WIRE
BRN WIRE
BRN/GRY WIRE
BRN/LT GRN WIRE
BRN/WHT WIRE
BRN/YEL WIRE
CAN C (+)
CIRCUIT BOARD
CLUSTER
COMPUTER DATA LINES SYSTEM
ENGINE COMPT)
FRONT WASHER FLUID LEVEL SENSOR (BOTTOM OF WASHER FLUID RESERVOIR)
FRONT WASHER PUMP MTR CTRL
FRONT WASHER PUMP RELAY
FRONT WIPER MOTOR
FSD B(+)
FUSE
HEADLAMP WASH RLY RTN
HOT AT ALL TIMES
LOW CTRL
LOW WASHER SW RTN
LT GRN WIRE
RED WIRE
SW SENS WIPER PRAK
UNDERHOOD POWER DISTRIBUTION CENTER (LEFT REAR CORNER OF
VIO/WHT WIRE
WASHER FLD LEV SW SENS
WHT WIRE
WINDSHIELD WASHER PUMP (IN BOTTOM OF WASHER RESERVOIR)
WIP HI/LOW CTRL
WIPER (HI)
WIPER HI SPEED CTRL OUTPUT
WIPER LOW RELAY
WIPER LOW SPEED CTRL OUTPUT
WIPER PARK SW SENS
YEL WIRE
Go to component: -> Wiper/washer circuit -> WASHER FLD LEV SW SENS
