Dodge Dart PF (2012-2016) turbocharger valve ctrl evap purge ctrl asd ctrl fd iat sig Wiring diagram

BLK/DK GRN WIRE BLK/VIO WIRE BLK/YEL WIRE BRN/BLK WIRE BRN/WHT WIRE CAMSHAFT 1/1 POSITION SOLENOID SOLENOID (UPPER RIGHT OF FRONT OF ENGINE) DK BLU/DK GRN WIRE DK BLU/LT GRN WIRE DK BLU/WHT WIRE ETC MOTOR, +/- EVAP PURGE CTRL FSD ASD RLY O/P GRY WIRE GRY/DK BLU WIRE INTAKE AIR INTAKE VARIABLE VALVE TIMING SOLENOID 2 (RIGHT CENTER OF TOP OF ENGINE) INTAKE VARIABLE VALVE TIMING SOLENOID 3 (RIGHT CENTER OF TOP OF ENGINE) INTAKE VARIABLE VALVE TIMING SOLENOID 4 (RIGHT REAR OF TOP OF ENGINE) MAP SIG BOOST PRESSURE SIG TP 2 SIG ETC MOTOR (+) ORG/BLK WIRE ORG/DK BLU WIRE ORG/DK GRN WIRE ORG/WHT WIRE POWERTRAIN CONTROL MODULE RED/VIO WIRE SOL 2 CTRL SOL 2 RTN SOL 3 CTRL SOL 3 RTN SOL 4 CTRL SOL 4 RTN THROTTLE BODY ASSEMBLY TP 1 SIG TP 2 SIG TP SNSR RTN TURBOCHARGER VALVE CTRL EVAP PURGE CTRL ASD CTRL FD IAT SIG VVA SOL 1 RTN VVA SOL 1 SIG WHT/BLK WIRE WHT/DK GRN WIRE WHT/RED WIRE WHT/VIO WIRE WHT/YEL WIRE YEL/BLK WIRE YEL/DK BLU WIRE
