Dodge Dart PF (2012-2016) power seat circuit breaker Wiring diagram

This page shows the only wiring diagram for the component.power seat circuit breaker, which is found in the car Dodge Dart PF (2012-2016). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..

Wiring diagram power seat circuit breaker (1 of 1)

Wiring diagram power seat circuit breaker for Dodge Dart PF (2012-2016)

Get access

1 2 3 4 5 6 7 8 9 DRV RECLINER DOWN SW SNSE BLK WIRE DOWN DRV DRIVER FRONT VERTICAL SEAT ADJUSTER MOTOR DRIVER HORIZONTAL SEAT ADJUSTER MOTOR DRIVER RECLINER SEAT ADJUSTER MOTOR DRIVER SEAT SWITCH DRV RECLINER DWN SW SNSE DRV RECLINER UP SW SNSE DRV SEAT FRT DRV SEAT HORZ FORWARD DRV FUSE 81 HOT AT ALL TIMES LT GRN WIRE LT GRN/DK GRN WIRE LT GRN/GRY WIRE LT GRN/LT BLU WIRE LT GRN/TAN WIRE LT GRN/VIO WIRE LT GRN/WHT WIRE ORG/ WIRE ORG/RED WIRE POWER SEAT CIRCUIT BREAKER REARWARD DRV RED WIRE UNDERHOOD POWER DISTRIBUTION CENTER (LEFT REAR CORNER OF ENGINE COMPT) UP DRV

Go to component: -> Power seats circuit -> POWER SEAT CIRCUIT BREAKER
