Dodge Dart PF (2012-2016) passenger seat track position sensor Wiring diagram
This page shows the only wiring diagram for the component.passenger seat track position sensor, which is found in the car Dodge Dart PF (2012-2016). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram passenger seat track position sensor (1 of 1)
BUCKLE SW SENSE
DK BLU/DK GRN WIRE
DK BLU/GRY WIRE
DK BLU/LT GRN WIRE
DK BLU/ORG WIRE
DK GRN WIRE
DK GRN/TAN WIRE
DRIV SEAT BELT RETRACT
DRIV SEAT BLT
DRIV SEAT DETECTION RTN
DRIV SEAT POSTN SNSR VOLT
DRIVER SEAT BELT BUCKLE TENSIONER/SWITCH
DRIVER SEAT BELT RETRACTOR TENSIONER (AT BASE OF DRIVER "B" PILLAR)
DRIVER SEAT TRACK POSITION SENSOR
GRY/LT GRN WIRE
LEFT SIDE THORAX AIR BAG (IN LEFT OUTBOARD SIDE OF FRONT SEATBACK CUSHION)
LT BLU/BLK WIRE
LT BLU/BRN WIRE
LT BLU/DK GRN WIRE
LT BLU/GRY WIRE
LT BLU/ORG WIRE
LT BLU/TAN WIRE
LT BLU/VIO WIRE
LT BLU/WHT WIRE
LT BLU/YEL WIRE
LT FT IMPT SNSR GND
LT FT IMPT SNSR SIG
LT GRN/BLK WIRE
LT GRN/BRN WIRE
LT GRN/GRY WIRE
LT GRN/ORG WIRE
LT GRN/VIO WIRE
LT GRN/WHT WIRE
LT GRN/YEL WIRE
OCCUPANT DETECTION SENSOR
PASS SEAT BLT SW SENSE
PASS SEAT DETECTION RTN
PASS SEAT OCCU DETECTION SIG
PASS SEAT POSTN SNSR VOLT
PASSENGER SEAT BELT BUCKLE TENSIONER/SWITCH
PASSENGER SEAT TRACK POSITION SENSOR
RIGHT SIDE THORAX AIR BAG (IN RIGHT OUTBOARD SIDE OF FRONT SEATBACK CUSHION)
RT FT IMPT SNSR GND
RT FT IMPT SNSR SIG
TAN/LT BLU WIRE
VIO/DK BLU WIRE
VIO/LT BLU WIRE
WHT/DK BLU WIRE
Go to component -> Supplemental restraints circuit (2 of 3) -> PASSENGER SEAT TRACK POSITION SENSOR
