Dodge Dart PF (2012-2016) lt blu red/ Wiring diagram
This page shows the only wiring diagram for the component.lt blu red/, which is found in the car Dodge Dart PF (2012-2016). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram lt blu red/ (1 of 1)
BASE PREMIUM
BLK/LT BLU WIRE
BREAKER
CLUSTER
COMPASS MODULE
DATA LINK CONNECTOR
DRIVER SEAT ADJUSTER LUMBAR SWITCH
DRIVER SEAT SWITCH
FROM BATTERY (DIAGRAM 1 OF 4)
FROM FRONT POWER DISTRIBUTION CENTER ASSEMBLY (DIAGRAM 3 OF 4)
FROM FUSE 23 FUSE (DIAGRAM 2 OF 4)
FUEL DOOR SWITCH
FUSE
FUSE 2
FUSE 4 FUSE 23
FUSE 6 FUSE
FUSE FUSE
GARAGE DOOR MODULE
GRY/RED WIRE
IN CAR TEMPERATURE SENSOR (AUTOMATIC A/C)
INSIDE REARVIEW MIRROR HUMIDITY A/C SENSOR HEATER CONTROL (AUTOMATIC A/C)
INTERIOR POWER DISTRIBUTION CENTER)
LEFT BLIND SPOT SENSOR
LT BLU RED/ WIRE
MEDIA STOPLAMP PORT SWITCH
ORG/ WIRE
PARK ASSIST MODULE
PNK WIRE
PNK/ YEL WIRE
PNK/YEL WIRE
POWER SEAT CIRCUIT
RADIO
REAR VIDEO CAMERA
RED ORG/ WIRE
RED WIRE
RED/DK BLU WIRE
RED/GRY WIRE
RED/LT GRN WIRE
RED/VIO WIRE
RIGHT BLIND SPOT SENSOR
STEERING CONTROL MODULE
SUNROOF MOTOR
TO FRONT POWER DISTRIBUTION CENTER ASSEMBLY (DIAGRAM 3 OF 4)
TO FUSE 19 (DIAGRAM 2 OF 4)
TRANSMISSION CONTROL MODULE
YEL PNK/ WIRE
YEL/RED WIRE
Go to component: -> Power distribution circuit (2 of 4) -> LT BLU RED/ WIRE
