Dodge Dart PF (2012-2016) left recirculation door actuator Wiring diagram

This page shows the only wiring diagram for the component.left recirculation door actuator, which is found in the car Dodge Dart PF (2012-2016). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..

Wiring diagram left recirculation door actuator (1 of 1)

Wiring diagram left recirculation door actuator for Dodge Dart PF (2012-2016)

Get access

1.4L A/C CLUTCH CTRL A/C COMPRESSOR A/C COMPRESSOR CLUTCH A/C COMPRESSOR SOLENOID AIR INLET DRIVE BLK WIRE BLOWER CTRL BLOWER MTR SPLY BRN/BLK WIRE BRN/DK GRN WIRE CTRL DEFROST MODE DRV DK BLU WIRE DK BLU/BRN WIRE DK BLU/DK GRN WIRE DK BLU/LT BLU WIRE DK BLU/LT GRN WIRE DK BLU/ORG WIRE DK BLU/TAN WIRE DK BLU/WHT WIRE DK BLU/YEL WIRE EVAP TEMP SNSR SIG FRT BLOWER FRONT LEFT RECIRCULATION DOOR ACTUATOR LT BLND DR DRV 1 LT BLND DR DRV 2 LT BLND DR SIG LT BLU/TAN WIRE MODE DR SIG OUTPUT PANEL MODE DRV PNK/YEL WIRE RECIR AIR INLET RECIR DR DRIVER RED WIRE REF VOLT SPLY SIG GND TAN/DK BLU WIRE TAN/ORG WIRE TAN/YEL WIRE VIO/RED WIRE

Go to component: -> Automatic a/c circuit (2 of 4) -> LEFT RECIRCULATION DOOR ACTUATOR
