Dodge Dart PF (2012-2016) interior power distribution center assembly Wiring diagram
This page shows the only wiring diagram for the component.interior power distribution center assembly, which is found in the car Dodge Dart PF (2012-2016). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram interior power distribution center assembly (1 of 1)
B (+) SPLY
BACK SIG
BLK WIRE
CAN C (+)
CLUTCH OIL PRESSURE SENSOR
COMPUTER DATA LINES SYSTEM
FUSE 14
FUSE 15
FUSE 25
FUSE 5
FUSED B (+)
GROUND
HOT AT ALL TIMES
INTERIOR POWER DISTRIBUTION CENTER ASSEMBLY
LT GRN/BRN WIRE
LT GRN/RED WIRE
LT GRN/VIO WIRE
PARK POSITION SIG
PNK/WHT WIRE
PUMP COMMAND
PUMP CONTROL
PUMP FEED
PUMP FEED BACK SIG
RED WIRE
RED/DK BLU WIRE
RED/LT GRN WIRE
RED/WHT WIRE
SMART DRIVE UNIT ASSEMBLY
SNSR GROUND
TRANSMISSION
TRANSMISSION CONTROL MODULE
TRANSMISSION PUMP MOTOR
TRANSMISSION WAKE UP SIG
UNDERHOOD POWER DISTRIBUTION CENTER
VIO/BLK WIRE
VIO/BRN WIRE
VIO/RED WIRE
VIO/WHT WIRE
WHT/BLK WIRE
WHT/ORG WIRE
WHT/YEL WIRE
YEL WIRE
YEL/BRN WIRE
YEL/LT GRN WIRE
YEL/RED WIRE
YEL/WHT WIRE
Go to component: -> Transmission circuit, w/ dual clutch transmission (1 of 3) -> INTERIOR POWER DISTRIBUTION CENTER ASSEMBLY
