Dodge Dart PF (2012-2016) heat seat Wiring diagram

1 2 3 CAN IHS (+) CAN IHS (-) BLK WIRE COMPUTER DATA LINES SYSTEM (LEFT END OF DASH) DK BLU WIRE FSD IGN SW OUT FUSE 1 FUSE 2 GND FSD IGN SW OUT HEAT SEAT HEATED SEATS MODULE HOT AT ALL TIMES HTD/ SEAT HTR CTRL HTR CTRL RT FT SEAT LEFT SEAT BACK VENT LEFT SEAT CUSHION HEATER LT FT HTD LT FT SEAT LT GRN WIRE LT GRN/ VIO WIRE LT GRN/BRN WIRE LT GRN/VIO WIRE PNK WIRE PNK/YEL WIRE RED WIRE RIGHT END OF DASH) RIGHT SEAT BACK VENT RIGHT SEAT CUSHION HEATER RT FT HTD SEAT RT FT SEAT SEAT SNSE SNSE RTN SNSR RTN TAN WIRE TAN/DK BLU WIRE TAN/WHT WIRE TAN/YEL WIRE TEMP SNSE VIO WIRE WHT TAN/ WIRE WHT WIRE WHT/DK BLU WIRE YEL WIRE
