Dodge Dart PF (2012-2016) fuel door switch Wiring diagrams
This page contains all the electrical diagrams for the component. fuel door switch, in which he is found in the car Dodge Dart PF (2012-2016). You can view various wiring diagrams where this component is used, as well as go to more detailed diagrams to see the complete connection and interaction in the system. All diagrams have links to quickly jump to the corresponding section with the component for easy viewing..
fuel door switch wiring diagram (1 of 4)
Go to component -> Fuel door release circuit -> FUEL DOOR SWITCH
fuel door switch wiring diagram (2 of 4)
BLK WIRE
BLK/BRN WIRE
DRIVER DOOR LATCH
DRIVER DOOR LOCK/ WINDOW SWITCH
DRIVER LUMBAR ADJUSTER SEAT SWITCH
DRIVER LUMBAR SEAT PUMP MOTOR
DRIVER SEAT SWITCH
DRIVER SMART MOTOR WINDOW SWITCH
DRIVER WINDOW MOTOR
FROM SPLICE
FUEL DOOR SWITCH
GRY/WHT WIRE
HEATED SEATS MODULE (W/ HEATED SEATS) COMFORT SEAT WHEEL
LEFT APPROACH LAMP
LEFT DETECTION BLIND SPOT LAMP
LEFT HEATER MIRROR
LEFT LEFT CUSHION VENT SEAT SEAT HEATER BACK
LEFT MIRROR TURN INDICATOR LAMP
MODULE (W/O HEATED SEATS)
OCCUPANT CLASSIFICATION MODULE
PASSENGER DOOR LATCH
RED WIRE
RIGHT APPROACH LAMP
RIGHT CUSHION SEAT HEATER
RIGHT DETECTION BLIND SPOT LAMP
RIGHT END OF DASH)
RIGHT HEATER MIRROR
RIGHT VENT SEAT BACK
STAR CONNECTOR DASH CAN C
Go to component -> Ground distribution circuit (4 of 4) -> FUEL DOOR SWITCH
fuel door switch wiring diagram (3 of 4)
AMB LHTING
BLK WIRE
CAN IHS (-)
CARGO LAMP
CIGAR LIGHTER
CLUSTER
COMPUTER DATA LINES SYSTEM
COURTESY
CTRL
DECKLID RELEASE SWITCH
DOME
DRIV CURTESY LMP
DRIV PNL LMPS
DRV PNL LMPS
ELECTRONIC OVERHEAD MODULE
FUEL DOOR SWITCH
GRY/ORG WIRE
LEFT PANEL LAMP
LEFT VANITY LAMP
LMP CTRL
LMP FD
ORG/GRN WIRE
ORG/GRY WIRE
ORG/LT GRN WIRE
ORG/VIO WIRE
REAR DOME
REAR DOME LAMP
RED WIRE
RIGHT REAR DOOR HANDLE LAMP
RIGHT REAR MAP POCKET LAMP
RIGHT VANITY LAMP
SUNROOF SWITCH
VIO WIRE
VIO/GRY WIRE
VIO/WHT WIRE
VIO/YEL WIRE
WHT WIRE
YEL/BRN WIRE
YEL/LT BLU WIRE
YEL/LT GRN WIRE
YEL/VIO WIRE
Go to component -> Interior lights circuit (2 of 3) -> FUEL DOOR SWITCH
fuel door switch wiring diagram (4 of 4)
BASE PREMIUM
BLK/LT BLU WIRE
BREAKER
CLUSTER
COMPASS MODULE
DATA LINK CONNECTOR
DRIVER SEAT ADJUSTER LUMBAR SWITCH
DRIVER SEAT SWITCH
FROM BATTERY (DIAGRAM 1 OF 4)
FROM FRONT POWER DISTRIBUTION CENTER ASSEMBLY (DIAGRAM 3 OF 4)
FROM FUSE 23 FUSE (DIAGRAM 2 OF 4)
FUEL DOOR SWITCH
FUSE
FUSE 2
FUSE 4 FUSE 23
FUSE 6 FUSE
FUSE FUSE
GARAGE DOOR MODULE
GRY/RED WIRE
IN CAR TEMPERATURE SENSOR (AUTOMATIC A/C)
INSIDE REARVIEW MIRROR HUMIDITY A/C SENSOR HEATER CONTROL (AUTOMATIC A/C)
INTERIOR POWER DISTRIBUTION CENTER)
LEFT BLIND SPOT SENSOR
LT BLU RED/ WIRE
MEDIA STOPLAMP PORT SWITCH
ORG/ WIRE
PARK ASSIST MODULE
PNK WIRE
PNK/ YEL WIRE
PNK/YEL WIRE
POWER SEAT CIRCUIT
RADIO
REAR VIDEO CAMERA
RED ORG/ WIRE
RED WIRE
RED/DK BLU WIRE
RED/GRY WIRE
RED/LT GRN WIRE
RED/VIO WIRE
RIGHT BLIND SPOT SENSOR
STEERING CONTROL MODULE
SUNROOF MOTOR
TO FRONT POWER DISTRIBUTION CENTER ASSEMBLY (DIAGRAM 3 OF 4)
TO FUSE 19 (DIAGRAM 2 OF 4)
TRANSMISSION CONTROL MODULE
YEL PNK/ WIRE
YEL/RED WIRE
Go to component -> Power distribution circuit (2 of 4) -> FUEL DOOR SWITCH
