Dodge Dart PF (2012-2016) fr pass dr lock sw mux Wiring diagrams
This page contains all the electrical diagrams for the component. fr pass dr lock sw mux, in which he is found in the car Dodge Dart PF (2012-2016). You can view various wiring diagrams where this component is used, as well as go to more detailed diagrams to see the complete connection and interaction in the system. All diagrams have links to quickly jump to the corresponding section with the component for easy viewing..
fr pass dr lock sw mux wiring diagram (1 of 2)
BLK WIRE
BODY CONTROL MODULE (BCM) (INTEGRAL TO INTERIOR POWER DISTRIBUTION CENTER)
CAN IHS (-)
COMPUTER DATA LINES SYSTEM
DRIVER WINDOW MOTOR
DRV WDW DRV DN
DRV WDW DRV UP
FR PASS DR LOCK SW MUX
FUSE
HOT AT ALL TIMES
IGN RUN ACC
LEFT FRONT WINDOW MOTOR
ORG/BRN WIRE
ORG/DK BLU WIRE
ORG/GRY WIRE
ORG/LT GRN WIRE
ORG/VIO WIRE
ORG/WHT WIRE
PASS WDW DRV (DN)
PASS WDW DRV (UP)
PASSENGER WINDOW/ DOOR LOCK SWITCH
PNK/YEL WIRE
RED WIRE
RF MASTER WDW SW (DN)
RF MASTER WDW SW (UP)
RIGHT FRONT WINDOW MOTOR
VIO/LT GRN WIRE
VIO/YEL WIRE
WHT WIRE
WHT/LT GRN WIRE
Go to component -> Power windows circuit, base (2 of 2) -> FR PASS DR LOCK SW MUX
fr pass dr lock sw mux wiring diagram (2 of 2)
BLK WIRE
BODY CONTROL MODULE (BCM) (INTEGRAL TO INTERIOR POWER DISTRIBUTION CENTER)
CAN IHS (-)
COMPUTER DATA LINES SYSTEM
DRIVER WINDOW MOTOR
DRV RTN DR LOCK SW
DRV WDW DRV DN
DRV WDW DRV UP
FR PASS DR LOCK SW MUX
FUSE
HOT AT ALL TIMES
IGN RUN ACC
LEFT FRONT WINDOW MOTOR
ORG/BRN WIRE
ORG/DK BLU WIRE
ORG/GRY WIRE
ORG/LT GRN WIRE
ORG/VIO WIRE
ORG/WHT WIRE
PASS WDW DRV (DN)
PASS WDW DRV (UP)
PASSENGER WINDOW/ DOOR LOCK SWITCH
PNK/YEL WIRE
RED WIRE
RF MASTER WDW SW (DN)
RF MASTER WDW SW (UP)
RIGHT FRONT WINDOW MOTOR
SMART WDW CTRL
TAN/BLK WIRE
VIO/DK GRN WIRE
VIO/LT GRN WIRE
VIO/YEL WIRE
WHT WIRE
WHT/LT GRN WIRE
Go to component -> Power windows circuit, premium (2 of 2) -> FR PASS DR LOCK SW MUX
