Dodge Dart PF (2012-2016) evic mux Wiring diagram
This page shows the only wiring diagram for the component.evic mux, which is found in the car Dodge Dart PF (2012-2016). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram evic mux (1 of 1)
1 2 CAN IHS(+) CAN IHS(-)
BLK WIRE
CAN C (+)
COMFORT SEAT WHEEL MODULE
COMPUTER DATA LINES SYSTEM
DIMM SW MUX
DK BLU WIRE
DK BLU/LT GRN WIRE
DK BLU/WHT WIRE
DK GRN WIRE
DK GRN/WHT WIRE
EVIC
EVIC MUX
EVIC MUX SIG
FSD IGN SW OUT
FUSE FUSE DISTRIBUTION CENTER (UNDER LEFT SIDE OF DASH, NEXT TO STEERING COLUMN)
GND FSD IGN SW OUT
GRY/DK BLU WIRE
HOT AT ALL TIMES
HTD STRNG
HTD STRNG WHL FD
HTD STRNG WHL RTN
INTERIOR POWER
LEFT STEERING WHEEL SWITCH SWITCH
LIN BUS
MUX RTN
PNK/YEL WIRE
PNL LMPS
SIG
SPEED CONTROL
STEERING CONTROL MODULE (UNDER SIDE OF STEERING COLUMN)
STEERING WHEEL HEATER SENSOR
WHL FD HTD STRNG
WHL RTN HTD STRNG
WHL SIG
WHL SIG HTD STRNG
WHT WIRE
WHT/DK BLU WIRE
YEL WIRE
Go to component -> Heated steering wheel circuit -> EVIC MUX
