Dodge Dart PF (2012-2016) dual fused horn horn control output Wiring diagram

This page shows the only wiring diagram for the component.dual fused horn horn control output, which is found in the car Dodge Dart PF (2012-2016). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..

Wiring diagram dual fused horn horn control output (1 of 1)

Wiring diagram dual fused horn horn control output for Dodge Dart PF (2012-2016)

Get access

BLK WIRE BODY CONTROL MODULE (INTEGRAL TO INTERIOR POWER DISTRIBUTION CENTER) BRN WIRE CAN C (+) CIRCUIT BOARD HORN SWITCH FSD CAN SENSE B(+) C (-) C (+) DRV COMPUTER DATA LINES SYSTEM DK BLU WIRE DUAL FUSED HORN HORN CONTROL OUTPUT FUSE GRY WIRE HORN RELAY HORN SW SENSE REM RAD SW SNSE RTN HORN SWITCH HORN SW SENSE HOT AT ALL TIMES LIN BUS REM RAD SW SNSE RTN SOUND SYSTEMS SPEED CONTROL SWITCH STEERING CONTROL MODULE (UNDER SIDE OF STEERING COLUMN) VIO WIRE WHT WIRE WHT/VIO WIRE YEL WIRE

Go to component: -> Horn circuit -> DUAL FUSED HORN HORN CONTROL OUTPUT
