Dodge Dart PF (2012-2016) decklid/liftgate ajar sw sens decklid/liftgate release drv Wiring diagram

This page shows the only wiring diagram for the component.decklid/liftgate ajar sw sens decklid/liftgate release drv, which is found in the car Dodge Dart PF (2012-2016). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..

Wiring diagram decklid/liftgate ajar sw sens decklid/liftgate release drv (1 of 1)

Wiring diagram decklid/liftgate ajar sw sens decklid/liftgate release drv for Dodge Dart PF (2012-2016)

Get access

BLK WIRE BODY CONTROL MODULE (INTEGRAL TO INTERIOR POWER DISTRIBUTION CENTER) BRN WIRE CAN C (-) CAN C (+) CIRCUIT BOARD COMPUTER DATA LINES SYSTEM DCKLD/LIFTGTE REL SW SIG DECKLID DOOR LATCH DECKLID RELEASE SWITCH DECKLID/LIFTGATE AJAR SW SENS DECKLID/LIFTGATE RELEASE DRV DECKLID/LIFTGATE RELEASE DRV DRIV PNL LMPS FSED B(+) FUSE HOT AT ALL TIMES LIFTGATE UNLOCK RELAY ORG/GRY WIRE RED WIRE RR DR ULK RLY CTRL TAN/LT GRN WIRE TAN/YEL WIRE UNDERHOOD POWER DISTRIBUTION CENTER (LEFT REAR CORNER OF ENGINE COMPT) VIO/ORG WIRE YEL WIRE

Go to component: -> Deck lid release circuit -> DECKLID/LIFTGATE AJAR SW SENS DECKLID/LIFTGATE RELEASE DRV
