Dodge Dart PF (2012-2016) 1 3 prk ast snsr sply prk ast sens gnd Wiring diagram

This page shows the only wiring diagram for the component.1 3 prk ast snsr sply prk ast sens gnd, which is found in the car Dodge Dart PF (2012-2016). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..

Wiring diagram 1 3 prk ast snsr sply prk ast sens gnd (1 of 1)

Wiring diagram 1 3 prk ast snsr sply prk ast sens gnd for Dodge Dart PF (2012-2016)

Get access

1 2 3 4 5 6 7 8 9 10 11 12 RUN RELAY CTRL 1 3 PRK AST SNSR SPLY PRK AST SENS GND 2 3 1 PRK AST SIG 10 PRK AST SENS GND PRK AST SNSR SPLY 2 3 1 PRK AST SIG 9 PRK AST SENS GND PRK AST SNSR SPLY 2 3 PRK AST SIG 11 PRK AST SENS GND PRK AST SNSR SPLY BLK WIRE CAN C (+) CAN C (-) GND COMPUTER DATA LINES SYSTEM FUSE 3 CENTER (UNDER LEFT SIDE OF DASH, NEXT TO STEERING COLUMN) GRY/LT BLU WIRE GRY/ORG WIRE HOT AT ALL TIMES INTERIOR POWER DISTRIBUTION PARK ASSIST 10 SENSOR PARK ASSIST 11 SENSOR PARK ASSIST 8 SENSOR PARK ASSIST 9 SENSOR PARK ASSIST MODULE PNK/YEL WIRE PRK AST SENS GND PRK AST SIG 8 VIO WIRE WHT WIRE WHT/DK GRN WIRE WHT/LT BLU WIRE WHT/ORG WIRE YEL WIRE

Go to component: -> Parking assistant circuit -> 1 3 PRK AST SNSR SPLY PRK AST SENS GND
