Dodge Dart PF (2012-2016) 1 2 3 4 5 6 auto hdlp sig sens gnd Wiring diagram

1 2 3 4 5 6 AUTO HDLP SIG SENS GND 1.4L 2.0L A/C CLUTCH CTRL A/C CLUTCH RELAY A/C COMPRESSOR CLUTCH A/C HEATER CONTROL AUTO HDLP SIG BLK WIRE BLOWER CTRL FRT BLOWER FRONT DEFROST MODE DRV PANEL MODE DRV BLOWER MOTOR RELAY BRN/BLK WIRE CAN IHS (+) CAN IHS (-) GND COMPUTER DATA LINES SYSTEM DISTRIBUTION CENTER (LEFT REAR CORNER OF ENGINE COMPT) DK BLU WIRE DK BLU/BRN WIRE DK BLU/DK GRN WIRE DK BLU/LT BLU WIRE DK BLU/LT GRN WIRE DK BLU/ORG WIRE DK BLU/TAN WIRE DK BLU/WHT WIRE DK BLU/YEL WIRE DK GRN WIRE FUSE FUSE 19 HOT AT ALL TIMES HOT W/ RUN/START RELAY ENERGIZED LEFT BLEND DOOR DRV 1 LEFT BLEND DOOR DRV 2 A/C COMPRESSOR CTRL LT BLU/TAN WIRE LT BLU/WHT WIRE OUTPUT PNK/YEL WIRE RED WIRE RED/LT GRN WIRE RED/VIO WIRE RELAY RUN WIRE SNSR GND SUN SENSOR (FRONT CENTER OF TOP OF DASH) TAN/DK BLU WIRE TAN/ORG WIRE TAN/YEL WIRE UNDERHOOD POWER VIO/DK BLU WIRE VIO/RED WIRE WHT WIRE WHT/VIO WIRE
