Dodge Dakota III facelift (2007-2011) wireless control module Wiring diagrams
This page contains all the electrical diagrams for the component. wireless control module, in which he is found in the car Dodge Dakota III facelift (2007-2011). You can view various wiring diagrams where this component is used, as well as go to more detailed diagrams to see the complete connection and interaction in the system. All diagrams have links to quickly jump to the corresponding section with the component for easy viewing..
Wiring diagram wireless control module (1 of 2)
A/C HEATER CONTROL
BLK WIRE
BLK/RED WIRE
BLK/WHT WIRE
BRAKE TRANSMISSION SHIFT SOLENOID
CENTER BEZEL LAMP
CLUSTER
CONSOLE POWER OUTLET
DATA LINK CONNECTOR
DRIVER SEAT HEATER SWITCH
ELECTRONIC OVERHEAD MODULE
GRY WIRE
HEADLAMP SWITCH
IGNITION SWITCH
INSTRUMENT PANEL POWER OUTLET
LT BLU WIRE
LT GRN WIRE
OCCUPANT RESTRAINT CONTROLLER MODULE
ORG/ WIRE
PASSENGER SEAT HEATER SWITCH
PASSENGER WINDOW/ DOOR LOCK SWITCH
STOP LAMP SWITCH
SUBWOOFER AMPLIFIER
SUBWOOFER AMPLIFIER RADIO
TOW/HAUL OVERDRIVE OFF SWITCH
TRANSFER CASE SELECTOR SWITCH
VIO WIRE
WHT WIRE
WIRELESS CONTROL MODULE
Go to component -> Ground distribution circuit (2 of 3) -> WIRELESS CONTROL MODULE
Wiring diagram wireless control module (2 of 2)
A/C HEATER CONTROL
ANTI-LOCK PASSENGER BRAKES SEAT HEATER MODULE SWITCH
BATTERY
BLK WIRE
BLK/WHT WIRE
BRN WIRE
CLUSTER
CONSOLE POWER OUTLET
DATA LINK CONNECTOR
DK BLU WIRE
DK GRN WIRE
DRIVER SEAT HEATER SWITCH
FROM FUSE 17 (DIAGRAM 1 OF 3)
FROM INTEGRATED POWER MODULE IGNITION RUN RELAY (DIAGRAM 1 OF 3)
FUSE
FUSE FUSE
FUSE STARTER RELAY TO FUSE 24 (DIAGRAM 3 OF 3)
GRY WIRE
IGNITION
IGNITION SWITCH
INSTRUMENT PANEL POWER OUTLET
INTEGRATED POWER MODULE (LEFT SIDE OF ENGINE COMPT)
IPM FRONT CONTROL MODULE FUSED B(+)
IPM FRONT CONTROL MODULE IGN RUN-ST OUTPUT
LOCK OFF
LT BLU WIRE
OCCUPANT RESTRAINT CONTROLLER MODULE
PNK (LEFT SIDE OF DASH) WIRE
PNK 4 32 PNK WIRE
PNK PNK WIRE
PNK WIRE
PNK/GRY WIRE
RADIO AMPLIFIER (PREMIUM)
REAR WHEEL ANTI-LOCK BRAKES ALL WHEEL ANTI-LOCK BRAKES
REAR WINDOW DEFOGGER RELAY
RED WIRE
RUN WIRE
TAN WIRE
TO SPLICE
VIO WIRE
WHT WIRE
WIRELESS CONTROL MODULE
YEL WIRE
Go to component -> Power distribution circuit (2 of 3) -> WIRELESS CONTROL MODULE
