Dodge Dakota III facelift (2007-2011) line prs sens out spd sens in spd sens sens gnd trns tmp sens Wiring diagram
This page shows the only wiring diagram for the component.line prs sens out spd sens in spd sens sens gnd trns tmp sens, which is found in the car Dodge Dakota III facelift (2007-2011). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram line prs sens out spd sens in spd sens sens gnd trns tmp sens (1 of 1)
5-VOLT
BLK WIRE
BRN/LT BLU WIRE
BRN/LT GRN WIRE
BRN/VIO WIRE
BRN/WHT WIRE
DK BLU/DK GRN WIRE
DK GRN WIRE
DK GRN/TAN WIRE
DK GRN/VIO WIRE
DK GRN/WHT WIRE
DK GRN/YEL WIRE
ENGINE COMPT)
FUSE 15
GROUND GROUND GROUND
HOT AT ALL TIMES
INPUT SPEED SENSOR (LEFT FRONT OF TRANSMISSION)
INTEGRATED POWER MODULE (LEFT SIDE OF ENGINE COMPT)
L/R PRESS PRESS PRESS
L/R SOL CTRL LP VFS CTRL
LINE PRESSURE SENSOR (RIGHT REAR OF TRANSMISSION)
LINE PRS SENS OUT SPD SENS IN SPD SENS SENS GND TRNS TMP SENS
LP VFS
LT BLU/RED WIRE
MS SOL CTRL
OD MS SOL SOL SOL
OD PRESS
OD SW SENSE TRNS RLY CTRL TRNS CTRL OUT
OUTPUT SPEED SENSOR (LEFT REAR OF TRANSMISSION)
POWERTRAIN CONTROL MODULE (RIGHT SIDE OF ENGINE COMPT)
PRESS SIG
SOL +
TEMPERATURE SENSOR
TOW/HAUL OVERDRIVE OFF SWITCH
TRANSMISSION CONTROL RELAY
TRANSMISSION SOLENOID/TRS ASSEMBLY (LEFT SIDE OF TRANSMISSION)
TRNS CTRL OUT
TRNS CTRL OUT L/R PRESS SW
TRS
TRS TRS
UD L/R SOL SOL SOL
UD PRESS
UD PRESS SW OD PRESS SW
UD SOL CTRL
VIO/PNK WIRE
VIO/RED WIRE
YEL/BLK WIRE
YEL/BRN WIRE
YEL/DK BLU WIRE
YEL/DK GRN WIRE
YEL/LT GRN WIRE
YEL/ORG WIRE
YEL/PNK WIRE
YEL/RED WIRE
YEL/WHT WIRE
Go to component -> Wiring diagram engine performance 4.7l flex fuel (5 of 5) -> LINE PRS SENS OUT SPD SENS IN SPD SENS SENS GND TRNS TMP SENS
