Dodge Dakota III facelift (2007-2011) backup lamp feed trailer tow 10-way inside wiring rearview mirror Wiring diagram
This page shows the only wiring diagram for the component.backup lamp feed trailer tow 10-way inside wiring rearview mirror, which is found in the car Dodge Dakota III facelift (2007-2011). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram backup lamp feed trailer tow 10-way inside wiring rearview mirror (1 of 1)
34 35 CAN C BUS (+) CAN C BUS (-)
5 SPEED A/T
BACKUP CAN C LAMP BUS (+) FEED
BACKUP LAMP FEED TRAILER TOW 10-WAY INSIDE WIRING REARVIEW MIRROR
BACKUP LAMP SWITCH (RIGHT REAR OF TRANSMISSION)
BACKUP SW SIG
BLK WIRE
BRN WIRE
CAN C BUS (+)
COMPUTER DATA LINES SYSTEM
DK GRN WIRE
FRONT CONTROL MODULE
FUSE 42
FUSED B (+)
HOT AT ALL TIMES
INTEGRATED POWER MODULE (LEFT SIDE OF ENGINE COMPT)
IPM
LEFT BACKUP LAMP
LT BLU WIRE
LT GRN WIRE
M/T
POWERTRAIN CONTROL MODULE (RIGHT SIDE OF ENGINE COMPT)
RIGHT BACKUP LAMP
TRANSMISSION RANGE SENSOR (LEFT SIDE OF TRANSMISSION)
TRANSMISSION SOLENOID/ TRS ASSEMBLY (LEFT SIDE OF TRANSMISSION)
WHT WIRE
WHT/LT BLU WIRE
WHT/LT GRN WIRE
YEL/ORG WIRE
Go to component -> Backup lamps circuit -> BACKUP LAMP FEED TRAILER TOW 10-WAY INSIDE WIRING REARVIEW MIRROR
