Dodge Dakota III facelift (2007-2011) 3 4 2 5 6 1 apps rtn 1 apps rtn 2 apps sig 1 apps sig 2 Wiring diagram

14 13 CAN B BUS (+) CAN C BUS (-) 16 17 25 36 APPS RTN 1 APPS RTN 2 APPS SIG 1 APPS SIG 2 2 3 1 8 3 18 42 41 CAN C BUS (+) CAN C BUS (-) WHEEL SPD SENS WHEEL SPD SENS 3 4 2 5 6 1 APPS RTN 1 APPS RTN 2 APPS SIG 1 APPS SIG 2 33 34 32 IN SPD SENS SENS GND OUT SPD SENS 34 15 18 S/C SW 1 SIG S/C SW RETURN S/C SW 2 SIG 6 15 28 38 21 29 ETC MTR (+) TP SENS RTN TP SIG 2 ETC MTR (-) TP 1 SIG 9 35 34 29 GND CAN C BUS (-) CAN C BUS (+) FUSED B (+) ACCEL/ RESUME ACCELERATOR PEDAL POSITION ANTI-LOCK BRAKES MODULE (LEFT SIDE OF ENGINE COMPT) AWAL RWAL BLK WIRE BLK/ORG WIRE BRK SW 1 SIG BRN WIRE BRN/DK GRN WIRE BRN/LT BLU WIRE BRN/LT GRN WIRE BRN/ORG WIRE BRN/WHT WIRE CLOCKSPRING (STEERING COLUMN) COAST COMPUTER DATA LINES SYSTEM DK BLU WIRE DK GRN WIRE DK GRN/VIO WIRE DK GRN/WHT WIRE DK GRN/YEL WIRE ENGINE CONTROLS SYSTEM ETC MTR (+) TP SENS RTN TP SIG 2 ETC MTR (-) TP 1 SIG FUSE 24 HOT AT ALL TIMES INPUT SPEED SENSOR (A/T) INSTRUMENT CLUSTER INTEGRATED POWER MODULE (LEFT SIDE OF ENGINE COMPT) LEFT SPEED CONTROL SWITCH NCA WIRE ON OFF ORG/ WIRE ORG/BRN WIRE OUTPUT SPEED SENSOR (A/T) PNK/GRY WIRE PNK/RED WIRE PNK/YEL WIRE POWERTRAIN CONTROL MODULE (RIGHT SIDE OF ENGINE COMPT) REAR ABS WHEEL SPEED SENSOR (NEAR RIGHT REAR RED WIRE RIGHT SPEED CONTROL SWITCH SENSOR (LEFT SIDE OF DASH) SET- STOP LAMP SWITCH (LOWER LEFT SIDE OF DASH) TAN/ORG WIRE TAN/YEL WIRE THROTTLE BODY (3.7L: TOP OF ENGINE) VIO WIRE VIO/ORG WIRE WHEEL, BY CROSSMEMBER) WHT WIRE WHT/LT BLU WIRE WHT/LT GRN WIRE WHT/ORG WIRE YEL/BLK WIRE YEL/PNK WIRE YEL/WHT WIRE
