Dodge Dakota III facelift (2007-2011) 1 2 ect sig sens gnd Wiring diagram

1 2 3 4 5 6 7 8 9 10 11 12 13 14 15 16 FUSED IGN SW OUT (RUN) GROUND 1 2 ECT SIG SENS GND 14 13 CAN B BUS (+) CAN B BUS (-) 27 20 SENS GND ECT SIG 3 2 1 PRESSURE SIG 5 VOLT SUPPLY FCM SENS RTN 34 35 CAN C (+) CAN C (-) 5 VOLT SUPPLY A/C CLUTCH RELAY A/C CLUTCH RLY CTRL A/C HEATER CONTROL A/C PRESSURE TRANSDUCER (RIGHT FRONT OF ENGINE COMPT) BLEND DOOR ACTUATOR (RIGHT SIDE OF HVAC UNIT) BLEND DOOR DRV BLK WIRE BLK/GRY WIRE BLK/ORG WIRE BLOWER MOTOR (FRONT OF HVAC UNIT) BLOWER MOTOR HIGH SPEED BLOWER MOTOR LOW SPEED BLOWER MOTOR RELAY BLOWER MOTOR RESISTOR (RIGHT SIDE OF HVAC UNIT) CAN B BUS (+) CAN B BUS (-) CAN B BUS (+) CLUSTER COMMON DOOR DRV COMPUTER DATA LINES COMPUTER DATA LINES SYSTEM DK BLU WIRE DK BLU/BRN WIRE DK BLU/DK GRN WIRE DK BLU/GRY WIRE DK BLU/LT BLU WIRE DK BLU/LT GRN WIRE DK BLU/ORG WIRE DK BLU/RED WIRE DK BLU/TAN WIRE DK BLU/VIO WIRE DK BLU/YEL WIRE DK GRN WIRE ENGINE CONTROLS SYSTEM ENGINE COOLANT TEMPERATURE SENSOR (RIGHT FRONT SIDE OF ENGINE) EVAPORATOR TEMPERATURE SENSOR (ON HVAC UNIT) EVAPORATOR TEMP SENS SIG FCM SENS RTN IPM FLOOR TO DEFROST MODE DOOR ACTUATOR FLOOR TO PANEL MODE DOOR ACTUATOR FRONT CONTROL MODULE (SIDE OF POWER DISTRIBUTION MODULE) FUSE 11 FUSE 59 FUSE 7 GROUND GRY WIRE GRY/PNK WIRE HOT AT ALL TIMES HOT AT ALL TIMES FUSE 35 HOT IN RUN OR START HOT W/ IGNITION RUN RELAY ENERGIZED IGN SW OUT (RUN) INTEGRATED POWER MODULE (LEFT LT BLU WIRE LT BLU/BRN WIRE LT BLU/ORG WIRE LT BLU/RED WIRE LT GRN/YEL WIRE MODE DOOR 1 DRV MODE DOOR 2 DRV ORG/ WIRE ORG/GRY WIRE PANEL LAMPS DRV PNK WIRE POWERTRAIN CONTROL MODULE (RIGHT SIDE OF ENGINE COMPT) PRESSURE SIG RECIRCULATION DOOR ACTUATOR (RIGHT SIDE OF HVAC UNIT) RECIRCULATION DOOR DRV SENS GND SIDE OF ENGINE COMPT) SYSTEM TRANSMISSIONS SYSTEM VIO WIRE VIO/ORG WIRE VIO/YEL WIRE WHT WIRE WHT/LT BLU WIRE WHT/LT GRN WIRE WHT/ORG WIRE YEL WIRE YEL/ORG WIRE
