Dodge Dakota III (2004-2007) transfer cluster case selector switch Wiring diagram
This page shows the only wiring diagram for the component.transfer cluster case selector switch, which is found in the car Dodge Dakota III (2004-2007). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram transfer cluster case selector switch (1 of 1)
A/C CLUTCH RELAY
ANTI-LOCK BRAKES MODULE
BATTERY
BLK WIRE
BRAKES
CLUSTER
DK GRN WIRE
DRIVER SEAT SWITCH
FROM IGNITION SWITCH (DIAGRAM 2 OF 3)
FROM INTEGRATED POWER MODULE (DIAGRAM 1 OF 3)
FRONT CONTROL MODULE
FUEL PUMP RELAY
FUSE
FUSE 17
FUSE 18
FUSE 9
FUSE FUSE
FUSIBLE LINK (8 GA-
GENERATOR
GRY WIRE
INSIDE OCCUPANT CLASSIFICATION MODULE REARVIEW MIRROR
IPM
IPM FRONT CONTROL MODULE
LT BLU WIRE
LT GRN WIRE
MODULE (DIAGRAM 1 OF 3)
NCA WIRE
OCCUPANT CLASSIFICATION MODULE
OCCUPANT PASSENGER AIR BAG ON/OFF INDICATOR LAMP RESTRAINT CONTROLLER MODULE
ORG/ WIRE
PNK PNK WIRE
PNK WIRE
POWERTRAIN CONTROL MODULE
RADIO
RED WIRE
SATELLITE RECEIVER
SENTRY KEY REMOTE ENTRY MODULE
STARTER
STOP LAMP SWITCH
TAN WIRE
TO IGNITION SWITCH (DIAGRAM 2 OF 3)
TO INTEGRATED POWER
TO INTEGRATED POWER MODULE (DIAGRAM 2 OF 3) FUSE
TRAILER TOW
TRAILER TOW ELECTRIC BRAKE WIRING
TRANSFER CLUSTER CASE SELECTOR SWITCH
Go to component -> Power distribution circuit (1 of 3) -> TRANSFER CLUSTER CASE SELECTOR SWITCH
