Dodge Dakota III (2004-2007) od sol ms sol sol Wiring diagrams
This page contains all the electrical diagrams for the component. od sol ms sol sol, in which he is found in the car Dodge Dakota III (2004-2007). You can view various wiring diagrams where this component is used, as well as go to more detailed diagrams to see the complete connection and interaction in the system. All diagrams have links to quickly jump to the corresponding section with the component for easy viewing..
od sol ms sol sol wiring diagram (1 of 2)
5-VOLT
BLK WIRE
BRN/YEL WIRE
DK BLU/DK GRN WIRE
DK GRN WIRE
DK GRN/TAN WIRE
DK GRN/VIO WIRE
DK GRN/WHT WIRE
DK GRN/YEL WIRE
FUSE 15
GRD
GROUND GROUND GROUND
HOT AT ALL TIMES
INPUT SPEED SENSOR (ON LEFT FRONT OF TRANSMISSION)
INTEGRATED POWER MODULE (LEFT SIDE OF ENGINE COMPT)
L/R PRESS PRESS
LINE PRESSURE SENSOR (ON RIGHT SIDE OF TRANSMISSION)
LINE PRS SENS OUTPT SPD SNS INPT SPD SENS SPD SENS GND TRNS TMP SENS
LR SOL CTRL PRES CTRL
LT BLU/RED WIRE
MS SOL CTRL
OD SOL MS SOL SOL
OD SW SENS TRNS RLY CTRL TRANS RLY OUT
OUTPUT SPEED SENSOR (ON LEFT REAR OF TRANSMISSION)
POWERTRAIN CONTROL MODULE (RIGHT SIDE OF ENG COMPT)
PRESS SIG
PRESS SOL
PRESS.
SENS GRD
SOL +
TEMP SENS
TOW/HAUL OVERDRIVE SWITCH
TRANS RLY OUT
TRANS RLY OUT L/R PRESS SW
TRANSMISSION CONTROL RELAY
TRANSMISSION SOLENOID/TRS ASSEMBLY (LEFT SIDE OF TRANSMISSION)
TRS
TRS OD PRESS
TRS TRS
UD PRESS
UD PRESS SW OD PRESS SW
UD SOL CTRL
UD SOL LR SOL
VIO/PNK WIRE
VIO/RED WIRE
YEL/BLK WIRE
YEL/BRN WIRE
YEL/DK BLU WIRE
YEL/DK GRN WIRE
YEL/ORG WIRE
YEL/PNK WIRE
YEL/RED WIRE
Go to component -> 4.7l, a/t circuit -> OD SOL MS SOL SOL
