Dodge Dakota III (2004-2007) map sens sig ret 1 sig 1 Wiring diagram
This page shows the only wiring diagram for the component.map sens sig ret 1 sig 1, which is found in the car Dodge Dakota III (2004-2007). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram map sens sig ret 1 sig 1 (1 of 1)
A/T
BLK WIRE
BRN WIRE
BRN/DK BLU WIRE
BRN/DK GRN WIRE
BRN/GRY WIRE
BRN/LT BLU WIRE
BRN/LT GRN WIRE
BRN/ORG WIRE
BRN/TAN WIRE
BRN/VIO WIRE
BRN/WHT WIRE
BRN/YEL WIRE
CAN C BUS (+) CAN C BUS (-) SCI TRANSMIT SCI TRANSMIT
COIL CONTROL 2 COIL CONTROL 1
COIL CONTROL 3
DATA LINK CONNECTOR (LOWER LEFT SIDE OF DASH)
DK BLU WIRE
DK BLU/DK GRN WIRE
DK BLU/ORG WIRE
DK BLU/TAN WIRE
DK BLU/YEL WIRE
ENGINE COOLANT TEMPERATURE SENSOR (RIGHT FRONT SIDE OF ENGINE)
FUSE 24
FUSE 36
FUSE 37
FUSE 7
FUSED B(+) IGN (START)
GEN FIELD ECT SENS IN TP SENS SIG
GROUND
HOT AT ALL TIMES
HOT IN RUN
HOT IN RUN OR START
HOT IN START
IGN (RUN-STRT) IGN (RUN)
INJ 4 CONTROL INJ 3 CONTROL INJ 2 CONTROL INJ 1 CONTROL
INTEGRATED POWER MODULE (LEFT SIDE OF ENGINE COMPT)
KNOCK SENSOR (LEFT REAR OF ENGINE)
MAP SENS SIG RET 1 SIG 1
OIL PRES SIG
OIL PRESSURE SWITCH (LEFT FRONT OF ENGINE)
PNK/GRY WIRE
PNK/RED WIRE
PNK/WHT WIRE
PNK/YEL WIRE
POWERTRAIN CONTROL MODULE (RIGHT SIDE OF ENG COMPT)
PWM 2/1 HTR
RED WIRE
SCI RECEIVE SCI RECEIVE
SENSOR GND
STARTING/CHARGING SYSTEM
VIO/BRN WIRE
VIO/GRY WIRE
VIO/ORG WIRE
WHT/GRY WIRE
WHT/LT BLU WIRE
WHT/LT GRN WIRE
WHT/ORG WIRE
YEL/PNK WIRE
Go to component -> Wiring diagram engine performance 3.7l (1 of 5) -> MAP SENS SIG RET 1 SIG 1
