Dodge Dakota III (2004-2007) cmp sig ckp sens sig sig 2 ret 2 iac mtr drvr Wiring diagrams
This page contains all the electrical diagrams for the component. cmp sig ckp sens sig sig 2 ret 2 iac mtr drvr, in which he is found in the car Dodge Dakota III (2004-2007). You can view various wiring diagrams where this component is used, as well as go to more detailed diagrams to see the complete connection and interaction in the system. All diagrams have links to quickly jump to the corresponding section with the component for easy viewing..
Wiring diagram cmp sig ckp sens sig sig 2 ret 2 iac mtr drvr (1 of 2)
28 29 30 31 32 33 34 35 36 37 38 IAC MTR SENS 5 VOLT SUPPLY IAT SIG
AIR CONDITIONING SYSTEM CRUISE CONTROL SYSTEM
ASD RELAY OUT SOL CTRL
ASD RELAY OUT SOL CTRL P/N SENS
AUTO SHT RLY
BLK WIRE
BRN WIRE
BRN/GRY WIRE
BRN/LT BLU WIRE
BRN/ORG WIRE
BRN/VIO WIRE
BRN/WHT WIRE
CMP SIG CKP SENS SIG SIG 2 RET 2 IAC MTR DRVR
CRUISE CONTROL SYSTEM
CRUISE SW SIG NVLD SW SIG
CRUISE VNT SOL
DK BLU/BRN WIRE
DK BLU/DK GRN WIRE
DK BLU/GRY WIRE
DK BLU/LT BLU WIRE
DK BLU/ORG WIRE
DK BLU/WHT WIRE
DK BLU/YEL WIRE
DK GRN/ORG WIRE
EVAP/PURGE SOLENOID (LEFT REAR OF ENGINE COMPT)
FUEL LVL RET
FUEL LVL SENS
FUEL PUMP MODULE (ON TOP OF FUEL TANK)
FUEL PUMP RLY STRTR MTR RLY
IAC MOTOR (ON THROTTLE BODY)
IGN SIG
INSTRUMENT CLUSTER
LT BLU/ORG WIRE
NATURAL VACUUM LEAK DETECTION ASSEMBLY (ON TOP OF FUEL TANK)
NVLD SOL CNTL 1/2 HTR CTRL PWM 2/2 HTR AC COMP CLTCH VAC SOL CTRL
PNK/RED WIRE
PNK/WHT WIRE
PNK/YEL WIRE
POWERTRAIN CONTROL MODULE (RIGHT SIDE OF ENG COMPT)
RED WIRE
STARTING/ CHARGING SYSTEM
VIO WIRE
VIO/GRY WIRE
VIO/LT BLU WIRE
VIO/ORG WIRE
VIO/WHT WIRE
VIO/YEL WIRE
YEL/ORG (OR YEL/DK BLU) WIRE
Go to component -> Wiring diagram engine performance 3.7l (4 of 5) -> CMP SIG CKP SENS SIG SIG 2 RET 2 IAC MTR DRVR
