Dodge Dakota III (2004-2007) brake fluid level sw sense Wiring diagram
This page shows the only wiring diagram for the component.brake fluid level sw sense, which is found in the car Dodge Dakota III (2004-2007). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram brake fluid level sw sense (1 of 1)
ANTI-LOCK BRAKES MODULE (AT LEFT SIDE OF ENGINE COMPT)
BLK WIRE
BLK/DK GRN WIRE
BRAKE FLUID LEVEL SENSOR (AT LEFT REAR OF ENGINE COMPT)
BRAKE FLUID LEVEL SW SENSE
BRAKE SW SIG
CAN C BUS (+)
DK GRN WIRE
DK GRN/ORG WIRE
DK GRN/PNK WIRE
DK GRN/WHT WIRE
DK GRN/YEL WIRE
FUSE 50
FUSE 60
GROUND FUSE B (+) REAR WHEEL SPD SENS SIG BRAKE SW SIG
HOT AT ALL TIMES
HOT IN RUN INTEGRATED POWER MODULE (AT LEFT SIDE OF ENGINE COMPT)
ORG/ WIRE
PNK WIRE
POWERTRAIN CONTROL MODULE (AT RIGHT SIDE OF ENGINE COMPT)
REAR ABS WHEEL SPEED SENSOR (NEAR RIGHT REAR WHEEL, BY CROSSMEMBER)
REAR WHEEL SPD SENS SUPPLY CAN C BUS(+) CAN C BUS(-) FUSED IGN SW OUT (RUN)
RED WIRE
TAN WIRE
TAN/RED WIRE
WHT/LT BLU WIRE
WHT/LT GRN WIRE
Go to component -> Rear wheel abs circuit -> BRAKE FLUID LEVEL SW SENSE
