Back-up lamps circuit for Dodge Dakota II (1997-2004)
Back-up lamps circuit
A/T 3.9L/5.9L
A/T 4.7L
AUTOMATIC DAY/NIGHT MIRROR
BACK-UP LAMP SWITCH (ON LEFT SIDE OF TRANSMISSION)
BLK WIRE
BRN/LT GRN WIRE
HOT IN RUN FUSE 26
J/C 1 (IN POWER DISTRIBUTION CENTER)
JUNCTION BLOCK
LEFT BACK-UP LAMP
M/T
RIGHT BACK-UP LAMP TRAILER TOW CONNECTOR
TRANSMISSION RANGE SENSOR (LEFT SIDE OF TRANSMISSION)
TRANSMISSION SOLENOID/TRS ASSEMBLY (IN TRANSMISSION, ON VALVE BODY ASSEMBLY)
VIO WIRE
VIO/BLK WIRE
