Dodge Dakota (1989-1994) to power distribution center below Wiring diagram
This page shows the only wiring diagram for the component.to power distribution center below, which is found in the car Dodge Dakota (1989-1994). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram to power distribution center below (1 of 1)
A/C COMPRESSOR CLUTCH RELAY
ABS DATA LINK CONNECTOR (ALL WHEEL ABS)
ABS POWER RELAY (ALL WHEEL ABS)
ALTERNATOR
AUTO SHUT DOWN RELAY
B/H CONNECTOR
BATTERY
BLK (OR RED) WIRE
BLK WIRE
BLK/GRY WIRE
BLK/RED WIRE
BLK/WHT WIRE
DK GRN WIRE
DOME LAMP RADIO
ENGINE STARTER RELAY
FAN CONTROL RELAY
FROM POWER DISTRIBUTION CENTER ABOVE
FUEL PUMP RELAY (3.9L, 5.2L ENGINES)
FUSE A
FUSE B (+)
FUSE C
FUSE D
FUSE E
FUSE F
FUSE G
FUSE H (NOT USED)
FUSE, RELAY BLOCK: (I/P
FUSIBLE LINK (HYPALON WIRE)
FUSIBLE LINK (HYPALON WIRE) 22 GA
GRY WIRE
HAZARD FLASHER TIME DELAY RELAY
OVERHEAD CONSOLE GLOVE BOX LAMP
PNK (OR RED) WIRE
PNK WIRE
PNK/BLK WIRE
PNK/WHT WIRE
POWER DISTRIBUTION CENTER
POWER MIRROR SWITCH
POWER- TRAIN CONTROL MODULE
RED WIRE
RED/DK GRN WIRE
RED/WHT WIRE
STARTER MOTOR
TO FUSES 5-8, 20 (FUSE, RELAY BLOCK:I/P)
TO IGNITION SWITCH
TO POWER DISTRIBUTION CENTER BELOW
UNDERHOOD LIGHT
WHT WIRE
Go to component -> Power distribution circuit (1 of 4) -> TO POWER DISTRIBUTION CENTER BELOW
