Dodge Dakota (1989-1994) power distribution Wiring diagrams
This page contains all the electrical diagrams for the component. power distribution, in which he is found in the car Dodge Dakota (1989-1994). You can view various wiring diagrams where this component is used, as well as go to more detailed diagrams to see the complete connection and interaction in the system. All diagrams have links to quickly jump to the corresponding section with the component for easy viewing..
Wiring diagram power distribution (1 of 5)
Go to component -> 2.5l, charging circuit -> POWER DISTRIBUTION
Wiring diagram power distribution (2 of 5)
AUTOMATIC SHUT DOWN RELAY (POWER DISTRIBUTION CENTER)
BATTERY
BB FUSE
BLK WIRE
DK BLU WIRE
DK GRN WIRE
DK GRN/ORG WIRE
FUSIBLE LINK
GEN FIELD
GENERATOR
ORG/ WIRE
POWER DISTRIBUTION
POWER DISTRIBUTION CENTER
POWERTRAIN CONTROL MODULE (RIGHT FENDER SIDE SHIELD) B+ ASD B+
RED WIRE
RED/WHT WIRE
STARTING SYSTEM
WHT WIRE
Go to component -> 3.9l, charging circuit -> POWER DISTRIBUTION
Wiring diagram power distribution (3 of 5)
A/T ONLY
B/H CONN PIN 31
B/H CONN PIN 49
BATTERY
BLK WIRE
BRN WIRE
BRN/YEL WIRE
FUSE
GRY WIRE
IGNITION SWITCH
LEFT HEADLAMP GROUND (LEFT FENDER SHIELD)
LOCK
M/T ONLY
PARK/NEUTRAL POSITION AND BACK-UP SWITCH (ON TRANSMISSION)
POWER DISTRIBUTION
POWER DISTRIBUTION CENTER
POWER- TRAIN CONTROL MODULE (RIGHT SIDE SHIELD) PARK NEUTRAL SWITCH
RED WIRE
RUN WIRE
STARTER MOTOR
STARTER RELAY (IN POWER DISTRIBUTION CENTER)
STARTER SOLENOID
YEL WIRE
Go to component -> 3.9l, starting circuit -> POWER DISTRIBUTION
Wiring diagram power distribution (4 of 5)
AUTOMATIC SHUT DOWN RELAY (POWER DISTRIBUTION CENTER)
BATTERY
BB FUSE
BLK WIRE
DK BLU WIRE
DK GRN WIRE
DK GRN/ORG WIRE
FUSIBLE LINK
GEN FIELD
GENERATOR
ORG/ WIRE
POWER DISTRIBUTION
POWER DISTRIBUTION CENTER
POWERTRAIN CONTROL MODULE (RIGHT FENDER SIDE SHIELD) B+ ASD B+
RED WIRE
RED/WHT WIRE
STARTING SYSTEM
WHT WIRE
Go to component -> 5.2l, charging circuit -> POWER DISTRIBUTION
Wiring diagram power distribution (5 of 5)
A/T ONLY
B/H CONN PIN 31
B/H CONN PIN 49
BATTERY
BLK WIRE
BRN WIRE
BRN/YEL WIRE
FUSE
GRY WIRE
IGNITION SWITCH
LEFT HEADLAMP GROUND (LEFT FENDER SHIELD)
LOCK
M/T ONLY
PARK/NEUTRAL POSITION AND BACK-UP SWITCH (ON TRANSMISSION)
POWER DISTRIBUTION
POWER DISTRIBUTION CENTER
POWER- TRAIN CONTROL MODULE (RIGHT SIDE SHIELD) PARK NEUTRAL SWITCH
RED WIRE
RUN WIRE
STARTER MOTOR
STARTER RELAY (IN POWER DISTRIBUTION CENTER)
STARTER SOLENOID
YEL WIRE
Go to component -> 5.2l, starting circuit -> POWER DISTRIBUTION
